Description
3300/12 88194-01 6 channel Temperature Monitor
The GE / Bently Nevada3300/12 88194-01Six-Channel Temperature Monitor provides six independent channels of on-line temperature monitoring. Each monitor is suitable for virtually all types of temperature measurements. The monitors accept inputs from up to six thermocouples (3300/30 TC Monitor) or resistance temperature detectors (3300/35 RTD Monitor), which are supplied separately.
Bentley Nevada 3300/12 88194-01 Specifications
| Recorder accuracy | All specified at +25°C (+77° F).
+4 to +20 mA: ±1.8% of the signal, ±0.09 mA offset. +1 to +5 Vdc: ± 2.2% of signal,±10 mV offset. 0 to -10 Vdc: ± 2.2% of signal, ±15 mV offset. |
| Output Impedance | 100 Ω. The minimum load resistance is 10 k Ω. |
| Voltage Compliance | 0 to +12 Vdc range across the load. Load resistance is 0 to 600 Ω when using the +4 to +20 mA option. |
| Operating Temperature | 0°C to +65°C (+32°F to +150°F). |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F). |
| Relative Humidity | To 95%, non-condensing. |
| EMC Directive | Certificate of Conformity: 158710 |
| Low Voltage Directive | Certificate of Conformity: 135300 |
| CSA/NRTL/C | Class I, Div 2
Groups A, B, C, D T4 @ Ta = +65 °C |
| Weigh | 2.8 kg (6.2 lbs.). |
Ordering Information
Six-Channel Temperature TC Input Monitor 3300/30 -AXX-BXX-CXX-DXX-EXX
A: Full-scale Range Option
01 0-200°F
02 0-300°F
03 0-400°F
04 0-500°F
05 0-1000°F
11 0-100°C
12 0-150°C
13 0-200°C
14 0-250°C
15 0-500°C
B: Transducer Input Option
01 Type J
02 Type K
03 Type T
04 Type E
C: Alarm Relay Option
00 No Relays
01 Epoxy-sealed
02 Hermetically-sealed
04 Spare Monitor-No SIM/SIRM
D: Agency Approval Option
00 Not required
01 CSA/NRTL/C
02 ATEX self-certification
E: Safety Barrier Option
00 None
01 External
02 Internal
Six-Channel Temperature RTD Input Monitor 3300/12 88194-01 -AXX-BXX-CXX-DXX-EXX
A: Full-scale Range Option
01 0-200°F
02 0-300°F
03 0-400°F
04 0-500°F
05 0-1000°F
11 0-100°C
12 0-150°C
13 0-200°C
14 0-250°C
15 0-500°C
B: Transducer Input Option
01 100 Ω platinum (0.00392)(3-wire)
02 100 Ω platinum (0.00385)(3-wire)
03 120 Ω nickel (3-wire)
04 10 Ω copper (3-wire)
05 100 Ω platinum (0.00392) (4-wire)
06 100 Ω platinum (0.00385) (4-wire)
07 120 Ω nickel (4-wire)
08 10 Ω copper (4-wire)
C: Alarm Relay Option
00 No Relays
01 Epoxy-sealed
02 Hermetically-sealed
04 Spare Monitor-No SIM/SIRM
D: Agency Approval Option
00 Not required
01 CSA/NRTL/C
02 ATEX self-certification
E: Safety Barriers
00 None
01 External
02 Internal
