Basic Product Information
Series: ABB CP600 Series Industrial Human-Machine Interface (HMI)
Model: CP651 (Order Number: 1SAP551100R0001)
Origin Certification: Made in Sweden, COO certification available; the casing is made of all-aluminum material, offering high durability
??️ Core Hardware Parameters
Display Configuration: 10.4-inch 4:3 aspect ratio TFT color touch screen, 800×600 resolution, supporting 64K color display
Performance Configuration: ARM Cortex-A9 dual-core 1GHz processor, 1GB DDR3 RAM + 4GB eMMC Flash storage
Communication Interfaces:
2×10/100Mbit Ethernet interfaces (supporting PROFINET/EtherNet/IP protocols)
1×RS-232/422/485 serial interface (supporting Modbus RTU protocol)
2×USB2.0 host interfaces, 1×SD card slot (supporting up to 32GB data log storage)
Power Supply Parameters: 18-30VDC wide voltage input, standard 24VDC power supply, overall power consumption approximately 24W
Physical Specifications: Dimensions 287×232×60mm, net weight 2.05kg; front panel IP66 protection rating, body IP20
Key Functional Features
Multi-language Support: Configurable in 32 languages, with online language switching support
Security Protection: 8-level user permission password protection, data encryption and backup recovery functions
Environmental Adaptability: Operating temperature 0-50℃, storage temperature -20-70℃; Fanless design, suitable for harsh industrial environments with dust and vibration
Software Compatibility: Supports ABB PanelBuilder/AutomationBuilder software development, enabling complex screen configuration, alarm management, trend analysis and other functions
Typical application scenarios
Power industry: Intelligent substation circuit breaker status monitoring, power curve display
Process industry: Equipment control and data acquisition in petrochemical and metallurgical industries
Manufacturing: Machine tool and production line operation interfaces and parameter settings
Infrastructure: Remote monitoring and leakage detection of oil and gas pipeline pump stations
