ABB DSDX404 Data Acquisition Module for Industrial Automation
The ABB DSDX404 Data Acquisition Module delivers precision performance for demanding industrial environments. Engineered to support real-time process monitoring and control, this high-density solution combines multi-channel capability with industrial-grade durability for critical automation systems.
Key Features
- 16 High-Precision Input Channels – Supports simultaneous multi-sensor integration for comprehensive process monitoring
- 12-Bit Resolution – Ensures ±0.05% measurement accuracy for critical control applications
- 100 kS/s Sampling Rate – Enables real-time data acquisition for dynamic process control
- Dual Communication Protocols – Modbus TCP/IP and Ethernet/IP compatibility for seamless system integration
- Industrial-Grade Design – IP65-rated enclosure with extended -40°C to +85°C operating range
- Compact DIN-Rail Mounting – Space-saving 190x110x50mm housing with 0.5kg lightweight construction
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand/Model | ABB DSDX404 |
| Power Requirements | 24V DC ±15% |
| Dimensions | 190 × 110 × 50 mm |
| Weight | 0.5 kg |
| Operating Temperature | -40°C to +85°C |
| Protection Rating | IP65 |
| Sampling Rate | Up to 100 kS/s |
| Communication | Modbus TCP/IP, Ethernet/IP |
Application Fields
Engineered for mission-critical operations, the DSDX404 excels in manufacturing automation, power generation monitoring, and oil & gas processing environments. Its robust design makes it ideal for deployment in harsh conditions requiring vibration-resistant measurement systems, including steel mills, chemical plants, and offshore platforms.
