ABB REF610C11LCLR Extended Protection Relay – Industrial Electrical System Guardian
The ABB REF610C11LCLR Extended Protection Relay combines precision engineering with cutting-edge digital technology to deliver mission-critical protection for industrial electrical systems. Designed for demanding environments, this compact relay provides multi-functional monitoring, fault detection, and control capabilities while ensuring seamless integration with modern automation architectures.
Key Features
- Precision Measurement: High-accuracy voltage (up to 500V) and current (up to 20A) monitoring with ±0.5% measurement error
- Multi-Protocol Communication: Supports Modbus RTU/TCP, Ethernet, and IEC 61850 protocols for system integration
- Space-Saving Design: Compact 160x160x105mm enclosure with DIN rail mounting for panel-constrained applications
- Advanced Protection Algorithms: Comprehensive protection against overcurrent, earth faults, phase imbalance, and voltage anomalies
- Intuitive Operation: Graphical LCD display with menu-driven configuration and real-time diagnostics
Technical Specifications
| Specification | Details |
|---|---|
| Brand/Model | ABB REF610C11LCLR |
| Power Requirements | 24-250V DC / 110-240V AC universal power supply |
| Dimensions (HxWxD) | 160 x 160 x 105 mm |
| Operating Temperature | -25°C to +70°C (-13°F to +158°F) |
| Protection Standards | IEC 60255-1, IEEE C37.90 |
Industrial Application Fields
Engineered for critical infrastructure protection across multiple sectors:
- Power generation facilities (turbine protection, generator monitoring)
- Oil & gas processing plants (explosion-proof zone electrical protection)
- Manufacturing automation systems (production line safeguarding)
- Railway traction power systems (overcurrent protection for DC traction networks)
- Renewable energy installations (solar/wind farm grid interface protection)
