Prerequisite Training packages

• ETAP for Protection Engineers (more info)
• ABB PCM600 Training Package (more info)

ABB REG670 Training package (Advanced level)

• Trainer: Dr. Saeed Roostaee (Profile on Linkedin)
• Pre-recorded videos
• Supplementary Files
• The course is still being recorded and new sessions will be added over time
• The course is licensed and you need a Windows computer to view the videos
• Download this course: contact us or leave a comment on this post
• For more info, please leave a comment on this post or contact us on WhatsApp: +989129613659

Course Details:

Configuration in the PCM600

• Generator, GSU, ET Transformer Unit Protection System
• Analog inputs, Generator & Transformer- CT and VT
• Generator protection functions (87G, 40G, 78, 50S, 46, 51V, 49S, 59, 27, 21G, 32R, 50/27, 64GB, 64R, 47, 64s-95 &100%, 81 O&U, 24G)
• GSU Trans Protection Functions (87T, 87GT, 64T(87N), 51N, 50/51T)
• Excitation Trans Protection Functions (50.51ET, 49ET)
• Trip matrix, Blocking logic
• Binary Outputs, LED Signal, Output Contact test
• Disturbance recorder
• IEC 61850 Signals

Parameter setting and Relay calculations

• 87G Generator Differential Protection
• 87T GSU Trans. Differential Protection
• 87GT Overall Differential Protection
• 40G Generator Field Failure Protection
• 78G Generator Pole Slipping Protection
• 50S, Generator Split phase overcurrent protection
• 46 Generator Negative Phase Sequence Protection
• 51V Generator Voltage-Dependent O/C Protection
• 49S Generator Stator Overload Protection
• 59G Generator Overvoltage Protection
• 21G Generator Underimpedance Protection
• 27G Generator Undervoltage Protection
• 32R Generator Reverse Power Protection
• 64S Generator 95%&100% Stator Earth Fault Protection
• 51/27 Generator Dead Machine Protection
• 64GB Generator Busbar Earth Fault Protection
• 64R Generator Rotor Earth Fault Protection
• 81O Generator Overfrequency Protection
• 81U Generator Underfrequency Protection
• 24G Generator Overflux Protection
• 47G Generator Fuse Failure Supervision
• 50/51ET Excitation Trans. Overcurrent Protection
• 49ET Excitation Trans. Overload Protection
• 51N-GSU Gen. Step-up Trans. Neutral Point OvercurrentProtection
• 64T GSU Trans. Restricted Earth Fault Protection
• 50/51T GSU Trans. Over Current Protection
• 50/51SST Station Service Trans. Over Current Protection
