ABB TK802F Redundant Control System – High-Availability Industrial Automation
The ABB TK802F Redundant Control System (Part No. 3BDM000213R1) delivers mission-critical reliability for industrial applications demanding uninterrupted operation. With dual-redundant architecture and advanced fault-tolerance mechanisms, this system ensures continuous process control in power generation, petrochemical, and manufacturing environments.
Key Features
- Triple Modular Redundancy – Dual CPUs with lock-step synchronization ensure 99.999% system availability
- High-Speed Processing – 30 kHz output frequency with sub-millisecond response times for precision control
- Modular Expandability – Hot-swappable I/O modules and communication cards for seamless system upgrades
- Environmental Resilience – 4.5 kg ruggedized chassis with IP20 protection for harsh industrial conditions
- Multi-Protocol Support – Integrated PROFIBUS, Modbus TCP, and Ethernet/IP interfaces
Technical Specifications
| Parameter | Specification |
|---|---|
| Power Requirements | 220V AC ±10%, 50/60 Hz |
| Dimensions | 450 x 300 x 150 mm (LxWxH) |
| Operating Temp | 0°C to 55°C (32°F to 131°F) |
| Certifications | CE, UL 61010, RoHS Compliant |
| Communication | PROFIBUS-DP, Modbus TCP, Ethernet/IP |
Application Fields
Engineered for critical infrastructure applications including:
- Nuclear power plant safety systems
- Offshore oil and gas platform controls
- Continuous-process manufacturing lines
- Emergency shutdown (ESD) systems
- Smart grid energy management
