Description
The 3300/05 rack serves as a durable, expandable, and easily accessible mounting platform for the 3300 Monitoring System. It is designed to house a Power Supply, System Monitor, and multiple 3300 Monitors. Each monitor position features a Signal Input/Relay Module slot located at the rear for convenient wiring.
The rack’s mainframe is crafted from injection-molded plastic infused with conductive antistatic material. This construction effectively dissipates electrostatic discharge (ESD), ensuring reliable protection in demanding industrial environments.
3300/05-AXX-BXX-CXX Options
| Option | Description |
|---|---|
| A | Rack Size Option (SDI/DDI Compatible) |
| 2 – 6-position rack | |
| B | Agency Approval Option |
| 0 – Not Required | |
| C | Mounting Option |
| 0 – Standard |
The Bently Nevada 3300/05 6-Position Rack is a standard installation rack system produced by Bently Nevada, belonging to its classic 3300 mechanical monitoring series. The following is a detailed introduction to this product:
I. Product Positioning and Core Functions
Mechanical Protection System
The 3300/05 frame is a mechanical protection system specifically designed for critical equipment (such as steam turbines, gas turbines, compressors, generators, etc.) to monitor parameters such as vibration, displacement, and rotational speed in real time, ensuring the safe operation of the equipment.
Modular Design
Supports 6 standard slots and can flexibly configure various monitoring modules (such as vibration monitoring module, displacement monitoring module, phase monitoring module, etc.) to meet the monitoring needs of different equipment.
Compatibility and Expandability
Compatible with all monitoring modules of the 3300 series and supports seamless upgrades.
Data interaction with process control systems (such as DCS, PLC) can be achieved through expansion interfaces (such as TDI module).
Technical Characteristics and Performance Parameters
Rack Structure
6-slot standard installation: Supports 6 full-height or half-height modules, optimizing space utilization.
EMI shielding design: Effectively reduces electromagnetic interference, ensuring signal stability.
Redundant power supply support: Optional dual power supply modules can be selected to enhance system reliability.
Environmental Adaptability
Operating Temperature: -20°C to +60°C, suitable for harsh industrial environments.
Protection Grade: IP52 (dustproof and water-resistant), suitable for indoor installation.
Communication and Interfaces
Modbus Protocol: Supports RS-232/RS-485 communication, facilitating integration with the upper computer.
Ethernet Option: Optional Ethernet module can be selected to achieve remote monitoring and data transmission.
