Bently Nevada 3300/16-13-01-02-00-00-00 XY/Gap Dual Vibration Monitor

The Bently Nevada 3300/16-12-01-01-00-00-00 XY/Gap Dual Vibration Monitor is designed for continuous monitoring of radial vibration and shaft position (gap) across two independent channels. It is particularly suited for applications where accurate vibration measurement and gap monitoring are critical for machinery protection. This model supersedes the older 3300/15 Dual Radial Vibration Monitor, offering additional functionality such as radial position gap alarms, which makes it more suitable for modern machinery health monitoring systems.

Configuration Breakdown (3300/16-12-01-01-00-00-00)

A: Full-scale Range Option (12)

• 0 – 100 µm pp: Full-scale measurement for vibration displacement, suitable for high-precision applications.
  This range is ideal for applications that require fine displacement measurements.

B: Transducer Input Option (01)

• 3300 8 mm, 3300 XL 8 mm, or 7200 5 mm and 8 mm Proximitor Sensor, 200 mV/mil: Compatible with the 3300 and 7200 series Proximitor® sensors, offering a 200 mV/mil output for precise measurement.

C: Alarm Relay Option (01)

• Epoxy-sealed: Features epoxy-sealed relays to provide a reliable method for triggering external alarms when vibration or shaft position exceeds predefined limits. These relays can be integrated with external systems for automated responses to machinery issues.

D: Agency Approval Option (00)

• Not Required: This model does not include specific agency certifications such as CSA/NRTL/C or ATEX.

E: Safety Barrier Option (00)

• None: This configuration does not include intrinsic safety barriers. However, external safety barriers are available as an option if needed for your specific application.

F: Trip Multiply Option (00)

• None: No trip multiplication is configured, meaning the system will not multiply the threshold values for triggering alarms.
