Bently Nevada 330180-50-05 3300 XL 5/8mm Proximitor Sensor

Product Description：

The 330180-50-05 is a part of the Bently Nevada 3300 XL 5/8mm Proximitor Sensor series, designed for precise and reliable non-contact displacement measurement in industrial applications. Manufactured in the U.S.A., this sensor is built to handle demanding environments, providing superior accuracy and performance in monitoring machinery vibration, alignment, and condition monitoring. The sensor accepts non-contacting proximity probes and extension cables, ensuring flexibility in system setup and application.This Proximitor Sensor comes with a 5.0-meter system length (16.4 feet) and is designed for panel mounting. It is ideal for applications that require CSA, ATEX, and IECEx agency approvals, which ensure safe operation in hazardous environments. It operates at a power supply of -17.5 Vdc to -26 Vdc, making it suitable for use in both standard and explosion-proof systems when barriers are in place.

Detailed Specifications

Product Name: 3300 XL Proximitor Sensor
Manufacturer: Bently Nevada
Product No: 330180-50-05
System Length: 5.0 meters (16.4 feet), panel mount
Proximitor Sensor Input:
Total Length and Mounting Option : 50 = 5.0 metre (16.4 feet) system length, panel mount
Agency Approval Option : 0 5 = CSA, ATEX, IECEx approvals
Proximitor Sensor Input : Accepts one non-contacting 3300-series 5 mm, 3300 8 mm or 3300 XL 8 mm Proximity Probe and Extension Cable.
Power : Requires -17.5 Vdc to -26 Vdc without barriers at 12 mA maximum consumption, -23 Vdc to -26 Vdc with barriers. Operation at a more positive voltage than -23.5 Vdc can result in reduced linear range.
Supply Sensitivity : Less than 2 mV change in output voltage per volt change in input voltage
Proximitor Sensor Material : A308 aluminum
Connector Material : Gold-plated brass or gold-plated beryllium copper
System Length : 5 or 9 metres (including extension cable) or 1 metre (probe only).

Frequently Asked Questions:

1.What type of probes are compatible with the 330180-50-05 sensor?
The 330180-50-05 sensor is compatible with 3300-series 5 mm probes, 3300 8 mm probes, and 3300 XL 8 mm probes, as well as extension cables.

2. Can the 330180-50-05 be used in hazardous locations?
Yes, this model has CSA, ATEX, and IECEx approvals, making it suitable for use in hazardous environments.

3. What is the operating voltage range for the sensor?
The sensor requires a power supply of -17.5 Vdc to -26 Vdc without barriers and -23 Vdc to -26 Vdc with barriers. Operating at voltages more positive than -23.5 Vdc can result in reduced linear range.
