Description
The Bently Nevada 330980-50-05 is part of the 3300 XL Series, designed to deliver precise non-contact vibration and position measurements in demanding industrial environments. This model offers a robust mechanical design, long-term reliability, and excellent compatibility with Bently Nevada monitoring systems.
Key Features and Technical Specifications
Sensor Specifications
- Part Number: 330980-50-05
- Series: 3300 XL Series
- Manufacturer: Bently Nevada (USA)
- Sensor Type: Proximity probe
- Sensing Range: 80 mils (2.0 mm) linear range
- System Length: 5 meters (Sensor + Extension Cable + Proximitor)
- Target Material: AISI 4140 steel
- Linearity: ±0.25% of full-scale output
Mechanical Design
- Sensor Tip Diameter: 8 mm
- Thread Size: 3/8-24 UNF
- Body Material: AISI 303 Stainless Steel
- Cable Armor: Optional 316 Stainless Steel flexible armor
- Environmental Protection: Fully sealed, corrosion-resistant
Electrical and Environmental
- Connector Type: Miniature coaxial connector (standard)
- Operating Temperature Range: –35°C to +120°C
- Storage Temperature: –50°C to +120°C
- Humidity Tolerance: 95%, non-condensing
- Vibration Tolerance: 10 g, 10–2000 Hz
- EMI/RFI Protection: Compliant with industrial EMC standards
Dimensions & Weight
- Total Cable Length: 5.0 meters (16.4 feet)
- Shipping Weight: 1.4 kg
Application Scenarios
The Bently Nevada 330980-50-05 is ideal for critical rotating machinery such as turbines, compressors, pumps, and gearboxes. Its precision and rugged construction ensure accurate performance even in harsh industrial settings.
When paired with a compatible 3300 XL Proximitor and extension cable, it forms a complete transducer system optimized for continuous monitoring and predictive maintenance.
