Description
The 3500/72M Rod Position Monitor is a 4-channel monitor that accepts input from our proximity transducers, conditions the signal to make various dynamic and static position measurements, and compares the conditioned signals with user-programmable alarms. The 3500 Rack Configuration software can program each channel of the 3500/72M to perform any of the following functions:
– Rod Position Measurement
– Rod Drop Measurement
– Hyper-Compressor Measurement
Monitor Type: 3500/72M
Channels Types: Reciprocating Compressor Rod Drop / Rod Position / Hyper
3500/72m manual
3500/72m rod position monitor
Bently Nevada 3500/72m manual
Bently Nevada 3500/72M Inputs And Outputs Specifications
| Inputs Signal | Accepts from 1 to 4 proximity probe signals. |
| Input Impedance | 10 kΩ |
| Rod Position | 3.94 mV/µm (100 mV/mil) or 7.87 mV/µm (200 mV/mil) |
| Rod Drop | 3.94 mV/µm (100 mV/mil) or 7.87 mV/µm (200 mV/mil) |
| HyperCompressor | 3.94 mV/µm (100 mV/mil) or 7.87 mV/µm (200 mV/mil) |
| Power Consumption | 7.7 watts, nominal |
| OK LED | Indicates when the 3500/72M is operating properly. |
| TX/RX LED | Indicates when the 3500/72M is communicating with other modules in the 3500 rack. |
| Bypass LED | Indicates when the 3500/72M is in Bypass Mode. |
| Buffered Transducer Outputs | The front of each monitor has one coaxial connector for each channel. Each connector is shortcircuit protected. |
| Output Impedance | 550 Ω |
| Transducer Power Supply | -24 Vdc |
3500/72M Rod Position Monitor Spares
176449-08 3500/72M Rod Position Monitor
140471-01 I/O Module with Internal Terminations
140482-01 I/O Module with External Terminations
135489-01 I/O Module with Internal Barriers and Internal Terminations
146479-01 3500/72M Rod Position Manual
