Overview The Bently Nevada 330130‑045‑11‑00 is a 3300 XL Armored FluidLoc extension cable designed for proximity probe systems. It provides reliable, secure connections between 3300 XL probes and Proximitor® sensors, ensuring signal integrity in harsh industrial environments. Certified to API 670 and CE marked.
Technical Specifications
- Part Number: 330130‑045‑11‑00
- Manufacturer: Bently Nevada
- Product Type: Extension Cable for Proximity Probe System
- System Family: 3300 XL Proximity Transducer System
- Cable Length: 4.5 m (14.8 ft)
- Cable Option: Armored FluidLoc
- Agency Approval: Not required
- Cable Type: 75 Ω triaxial coaxial, FEP insulated
- Connector Type: ClickLoc™ gold-plated coaxial connectors
- Capacitance: 69.9 pF/m
- Minimum Bend Radius: 25.4 mm (1 in)
- Max Connector Torque: 0.565 N·m (5 in‑lb)
- Operating Temperature: −52 °C to +177 °C
- Storage Temperature: −40 °C to +85 °C
Installation Notes
Connect one end to the 3300 XL 8 mm proximity probe and the other to the Proximitor® sensor Route cable to avoid sharp bends and mechanical stress Use armored FluidLoc® cables in oil-rich or hazardous environments to prevent leakage and damage Ensure proper grounding and shielding for EMC compliance
