The CX5200 series is an embedded controller based on PC control technology from Beckhoff
Hardware architecture
CPU module: core processing unit, responsible for running the control program and operating system, multi-core processor, support a variety of operating systems, memory configuration can be selected according to demand, storage support SSD and CFast card and other media.
Power module: Usually 24V DC input, provide stable power supply, with overvoltage, overcurrent and short circuit protection.
Communication module: Ethernet interface support 10/100/1000BASE-T Ethernet standard; PROFINET interface can realize high-speed communication with PROFINET equipment; The EtherCAT interface enables high-speed data exchange with EtherCAT slave devices.
I/O module: Support digital input/output module, analog input/output module and special function module, such as temperature measurement module, motion control module.
Expansion ports: Provides expansion ports such as PCI/PCIe slots, USB ports, and serial ports.
Application field
Machinery manufacturing: such as CNC machine tools, packaging machinery, injection molding machines, etc.
Process control: such as chemical, pharmaceutical, food processing, etc.
