EMERSON 1X00416H01 Relay Control Module – Industrial-Grade Circuit Switching Solution
Engineered for precision and durability, the EMERSON 1X00416H01 Relay Control Module delivers reliable circuit switching in demanding industrial environments. This DIN-rail mountable module ensures stable operation with its robust electrical ratings and environmental resilience, making it ideal for automation systems requiring fail-safe control.
Key Features
- High-Performance Electrical Ratings: 220V AC/DC rated voltage with 5A switching capacity ensures stable operation in high-load circuits
- Multi-Voltage Compatibility: 125VAC/30VDC contact rating supports both AC and DC applications
- Industrial-Grade Isolation: 2500VAC dielectric withstand voltage and ≥100 MΩ insulation resistance protect against electrical interference
- Extreme Temperature Tolerance: Operational from -40°C to +85°C for reliability in harsh environments
- Long-Term Durability: 250VAC/2A switching capacity with gold-plated contacts for extended service life
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand/Model | EMERSON 1X00416H01 |
| Power Requirements | 220V AC/DC, 5A |
| Operating Temperature | -40°C to +85°C |
| Contact Rating | 125VAC / 30VDC |
| Dielectric Strength | 2500VAC |
| Installation Method | DIN Rail Mounting |
Application Fields
Designed for critical industrial automation systems, this relay module excels in:
- Process control systems in chemical and energy sectors
- Machinery automation with high-voltage requirements
- Harsh environment applications (extreme temperatures, vibration)
- Emergency shutdown systems requiring fail-safe switching
- Power distribution systems with mixed AC/DC loads
