EMG LID43.03 Multi-channel Gas Detection Module is a key component designed for gas detection and alarm systems. The following is a detailed overview of its core features:
I. Core Functions
Multi-channel alarm output
Support for rising (Rising), falling (Falling), STEL (short-term exposure limit) and LTEL (long-term exposure limit) alarms, as well as rate alarms (RATE), and can handle multiple gas concentration thresholds simultaneously, meeting the requirements of complex industrial scenarios.
Single-channel or multi-channel alarm update function is provided to ensure real-time performance.
Remote control and reset
Support for remote inhibition and reset inputs, facilitating remote operation of the centralized monitoring system and reducing the frequency of on-site maintenance.
Relay output delay control
The on-off time of the relay can be independently set with delay to avoid false alarms caused by fluctuations in gas concentration and improve system stability.
Analog output
Provides optional 0-20mA or 4-20mA isolated monitor output, facilitating seamless integration with PLC, DCS and other control systems for data remote transmission and recording.
Hardware Design
Modular structure
Adopts 1-inch (2.54cm) wide standard card design, compatible with rigid custom racks, supporting 19-inch (17 slots) and half 19-inch (9 slots) specifications, capable of accommodating up to 16 or 8 channel control cards and 1 engineering card.
The sub-rack integrates the engineering card and DC input card, simplifying wiring and meeting the wiring requirements of different customers.
Independent channel control
Each single-channel control card operates independently, including sensor drive circuits, alarm detection and gas concentration display functions, ensuring no interference between channels and improving system reliability.
Field interface and relay card
Provides interface connections between the control card and the field gas sensors and outputs alarm signals to the field equipment, supporting simultaneous monitoring of multiple gases.
Communication and Calibration
Serial communication support
Uses the Modbus protocol for serial communication, compatible with mainstream industrial network architectures, facilitating data collection and system integration.
Engineering card configuration
Through dedicated engineering cards, realize main alarm update, event printer connection and other functions, simplifying system configuration and maintenance.
Support for remote calibration and operation, reducing the difficulty of on-site debugging.
High-precision calibration
Uses dedicated engineering cards for calibration, with simple operation, ensuring detection accuracy meets industrial standards.
Environmental Adaptability
Industrial-grade design
Complies with EMC (electromagnetic compatibility) standards, with strong anti-interference capabilities, suitable for harsh industrial environments such as high temperature, high humidity and high dust.
Rack system design meets the wiring requirements of different customers, with the relay and field wiring separated, enhancing system safety.
Wide temperature operating range
Adapts to a working temperature range of -40°C to +70°C, meeting the stability operation requirements in extreme environments.
Application Scenarios
Industrial safety monitoring
Used in industries such as petrochemicals, metallurgy and mining, for real-time monitoring of combustible gases (such as CH₄, H₂), toxic gases (such as H₂S, SO₂) and oxygen concentration, preventing explosion or poisoning accidents.
Environmental governance
In scenarios such as sewage treatment plants and waste disposal sites, detecting sulfur dioxide (H₂S), ammonia (NH₃) and other malodorous gases, assisting in environmental compliance.
Emergency rescue
Integrated into portable gas detectors, providing real-time gas concentration data for rescue personnel, supporting scientific decision-making and safe operations.
Selection Suggestions
Channel number selection: Choose 19-inch or half 19-inch racks based on the number of monitored gas types to ensure scalability.
Output signal: Prefer 4-20mA isolated output for easy long-distance transmission and anti-interference.
Alarm function: Configure STEL/LTEL alarms and rate alarms according to safety standards requirements.
Calibration convenience: Select models that support remote calibration to reduce maintenance costs.
