Product Details:
| Brand Name | EPRO |
| Model | PR6423/110-100 |
| Catalog | PR6423 |
| Origin | Germany |
| Dimension | 16*16*12cm |
| Weight | 1kg |
| HS Code | 8537101190 |
| Payment | T/T |
| Sales Price | $1500 |
| Warranty | 12 months |
| Lead time | 3-5 work days |
Additional Information:
| Technical Data differing from Standard | |
| Material | Sensor Tip (Epoxy Resin)
Case (Stainless Steel with EPDM O-Ring Sealing) Cable (Polyolefine) |
| Operating Temperature Range | -35 to +80°C (-31 to 176°F) |
| Radiation Resistance | Sensor & 1m Cable: up to 80Mrad Extension Cable & Converter: up to 0.1Mrad |
| Calculated Lifetime @ radiation of 0.5Sv/h: | With neutron radiation: 18.26 years With beta or gamma radiation: 183 years |
| Certifications | No hazardous area certification available! |
Description:
Performance:
- Linear Measurement Range: 2 mm (80 mils)
- Initial Air Gap: 0.5 mm (20 mils)
- Incremental Scale Factor (ISF): ISO: 8 V/mm (203.2 mV/mil) ± 5%
- @ temperature range 0 to 45°C
- (+32 to +113°F)
- Deviation from best fit straight line (DSL): ± 0.025 mm (± 1 mil) @ temperature range 0 to 45°C (+32 to +113°F)
Environmental, General:
- Protection Class: IP66, IEC 60529
- Operating Temperature Range: Sensor incl. 1m Cable: -35 to +180°C (-31 to 356°F) Cable & Connector: -35 to +150°C (-31 to 302°F)
- Material: Sensor Tip (PEEK Polyether Ketone), Case (Stainless Steel) Cable (PTFE Polytetrafluoroethylene), Connector (Brass, nickel-plated)
