FC-PSU-240516 analog output module

FC-PSU-240516 5021493390FCPSU240516(136-011194D) POWER MODULE

Brand/Manufacturer Honeywell

Part Number: FC-PSU-240516

Alternate Part Number: 136-011194D

Description: Power Supply Unit

Dimensions:3.5×22.5×17.5cm

Weight:0.88 kg

Engineering environment

The Safety Builder improves engineering and design efficiency. With the newlydeveloped Network Configurator, designing safety networks has never beeneasier. With simple drag & drop functionality, a complete network can bedesigned within minutes. Difficult and complex configurations no longer need tobe programmed, as the Safety Builder will do this and will save valuableengineering and testing time. Moreover, the complete network design isavailable on a one-page view, no longer requiring additional documentation andprogramming.

The proven in use Functional Logic Diagram (FLD) Editor facilitates fast andeffective application design allowing clear and distinct views of all logic, with fullcompliance to IEC 61131 standards. Logic inputs, outputs, and symbols areplaced with drag & drop functionality from the toolbar and are easilyconfigurable.

Safety Manager R120 will provide several enhancements to make the life of aproject engineer easier. Amongst others, the following features have beenincluded:

1.Copy application from another plant

2.Bulk copy of points

3.Bulk rename of points

4.Bulk copy FLD

5.Multi-users using one Safety manager database

6.Multi-users connecting to one Safety manager controller

7.Multi-site support to allow for distributed logic development
