Description
Fieldbus Modules provide the interface between process sensors/actuators and the redundant Fieldbus. The modules appropriately convert the electrical input/output signals used by field devices to permit communication with these devices via the
Fieldbus. The Fieldbus Modules available for use with I/A Series systems are partitioned into three categories; main modules, expandable main modules, and expansion modules.
Main Modules
Each main module independently connects to the Fieldbus, has a fixed (that is, non-expandable) capacity of field input/output channels, and performs the signal conversions and other related operational executions required for these resident input/output channels. All main modules contain the following:
Digital processor
Dual transceivers (for Fieldbus communications)
Memory
dc/dc power converter (accepts redundant power inputs)
Security logic
Power security and on-line self-check circuits.
Input Signal:
When replacing an expansion FBM42A to FBM219: 8 channel Voltage
Monitor external source 60 V dc
Maximum voltage
Logic Zero: 0 to 5 V dc
Logic One: 15 to 60 V dc 6 mA maximum input current
1 KΩ Maximum On-state resistance
100 KΩ Minimum Offstate resistance
When replacing an expansion FBM42C to FBM219:
Contact sense internal source
24 V dc ±20% Open circuit voltage
5 mA maximum short circuit current
1 KΩ Maximum On-state resistance
100 KΩ Minimum Offstate resistance
Output Signal
When replacing an expansion FBM42A/C to FBM219:
8 channel Output
Switch external source
60 V dc Maximum voltage
0.4 V maximum
voltage drop @ 1 A
2.25 A maximum current
12 A maximum current per TA
10 A surge current limit for 20 msec maximum
Shorted load duration: indefinite (duty-cycle limited)
0.5 mA maximum off-state leakage
PA: P0924JB
Fieldbus Modules
| FBM01 – 0 to 20 mA Input Interface module |
| FBM02 – Thermocouple/mV Input Interface module |
| FBM03 – RTD Input Interface module |
| FBM04 – 0 to 20 mA I/O Interface module |
| FBM05 – Redundant 0 to 20 mA I/O Interface C4 F2, F3 |
| FBM06 – Pulse Input, 0 to 20 Output Interface module |
| FBM07 – Contact/dc Input Interface module |
| FBM08 – 120 V ac Input Interface module |
| FBM09 – Contact/dc Input/Output Interface module |
| FBM10 – 120 V ac Input/Output Interface module |
| FBM11 – 240 V ac Input/Output Interface module |
| FBM12 – Contact/dc Expansion Input Interface module |
| FBM13 – 120 V ac Expansion Input Interface module |
| FBM14 – Contact/dc Expansion Input/Output Interface module |
| FBM15 – 120 V ac Expansion Input/Output Interface module |
| FBM16 – 240 V ac Expansion Input/Output Interface module |
| FBM17 – 0 to 10 V dc, Contact/dc Input/Output Interface module |
| FBM20 – 240 V ac Input Interface module |
| FBM21 – 240 V ac Expansion Input Interface module |
| FBM22 – Single 0 to 20 mA I/O Auto/Manual Interface module |
| FBM24 – Contact/125 V dc Input Interface module |
| FBM25 – Contact/125 V dc Expansion Input Interface module |
| FBM26 – Contact/125 V dc I/O Interface module |
| FBM27 – Contact/125 V dc Expansion I/O Interface module |
| FBM33 – RTD Input Interface module |
| FBM41 – High Power Contact/dc Input/Output Interface module |
| FBM42 – High Power Contact/dc Expansion Input/Output Interface module |
| FBM43 – Dual Baud Rate Intelligent Transmitter Interface Module |
| FBM44 – Dual Baud Rate Intelligent Tranmitter/0 to 20 mA Output Interface Module |
| FBM46 – Redundant Intel Transmitter/0 to 20 mA Interface Module |
| P0903ZE – Fieldbus Isolator Module |
