GE IC698CHS017B Programmable Logic Controller

Product Positioning and Functions
The GE IC698CHS017B is a high-performance programmable logic controller (PLC) CPU module launched by General Electric Automation (GE Automation). It belongs to the PACSystems RX7i series. Its core functions include:
Real-time control and data processing: Utilizing a 700MHz Pentium III floating-point microprocessor, it executes user-written control programs, manages I/O modules, and achieves automated control.
Communication management: Equipped with two Ethernet ports and three serial ports (RS-232/RS-485), it supports various industrial communication protocols (such as Modbus/TCP, PROFIBUS DP, DeviceNet), enabling data exchange between devices.
System expansion: Supports connection of other rack modules through the VME backplane, allowing flexible expansion of system functions (such as adding I/O channels, special function modules).
Fault diagnosis and redundancy: Features self-diagnosis capabilities and supports redundant configuration, enhancing system reliability.

Key technical parameters
Processor: 700MHz Pentium III floating-point microprocessor, standard execution speed 0.14 milliseconds per 1000 Boolean contacts.
Memory:
10MB RAM (volatile memory, requires CMOS battery support).
10MB Flash (non-volatile memory, used to store user data, programs, and operating system firmware).
Communication interface:
Ethernet port: Two 10/100Mbps RJ45 interfaces, support TCP/IP configuration.
Serial port: Three (RS-232/RS-485), the third port is the station manager port.
Operating temperature: -20°C to 60°C, suitable for harsh industrial environments.
Power supply: 24V DC power supply, current rated value 4.3A.
Physical size: 6U high, 21HP wide, 233mm deep, weight approximately 2.3 kilograms.

Application scenario
Manufacturing: Controlling production lines, assembly processes and material handling systems (such as complex motion control, high-speed packaging, injection molding).
Process control: Managing industrial processes such as oil and gas refining, chemical processing, power generation, etc. (such as temperature, pressure, flow monitoring and regulation).
Building automation: Controlling HVAC (Heating, Ventilation, and Air Conditioning), lighting and security systems.
Transportation sector: Managing traffic signals, railway signals and vehicle automation systems.
Other fields: Food processing, semiconductor manufacturing, packaging, textiles, printing, etc.
