IS200EDCFG1A is designed as GE Exciter DC Feedback, it can handles bridge dc voltage and current feedback.
IS200EDCFG1A board measures field current and field voltage at the SCR bridge, and interfaces to the EISB board in the controller over a high-speed fiber-optic link. The fiber optics provides voltage isolation between the two boards, and high noise immunity. The fieldvoltage feedback circuit provides seven selector settings to scale down the bridgevoltage, depending on the type of bridge application.The exciter is a flexible modular system that can be assembled to provide a range ofavailable output currents and several levels of system redundancy. These optionsinclude power from a potential, compound, or auxiliary source. Single or multiplebridges, warm backup bridges, and simplex or redundant controls are available. The EX2100 hardware is contained in three cabinets as follows:
• control cabinet for the control, communication, and lO boards
• auxiliary cabinet for field flashing and protection circuits such as de-excitation and shaft voltage suppression
• power conversion cabinet for the power SCR cells, cooling fans, dc contactors.and ac disconnect
