MM300-GEHDSCABD Technical Specifications
| Manufacturer | General Electric Multilin (GE) |
| Manufacturing Location | Markham, Ontario, Canada |
| Software | EnerVista MM300 |
| Model Number | MM300-GEHDSCABD |
| Graphical Control Panel Pushbuttons | Start A, Start B, Stop, plus 11 LCD screen display control keys |
| Graphical Control Panel Size | width 153mm, height 102mm, depth 35mm |
| Graphical Control Panel LCD | 3.5-inch color, 320 by 240 pixels |
| Event Recorder Capacity | 256 events |
| Storage/Shipping Temperature Range | -40°C to +90°C |
GE Multilin MM300 Series Features
- The Multilin MM300 Motor Management lineup consists of control units designed by General Electric’s industrial automation division.
- These modular units offer motor protection and control systems specifically for low-voltage motor applications.
- The MM300’s frame is built for maximum compactness and space efficiency.
- Their application functions include management, protection, and control of low-voltage, alternating current motors.
- Advanced automation capabilities provide extensive customization for motor protection based on user needs.
- The controller’s processing abilities are streamlined and integrated into the MM300 line’s software, primarily due to the FlexLogic programming software.
- FlexLogic eliminates the reliance on local, on-site programmable logic controllers (PLCs).
- These units reduce the space required by eliminating the need to integrate numerous individual attachment devices with motors.
- Possible network connections for the MM300 line include:
- Modbus RTU
- Modbus TCP/IP
- Profibus DPV1
- Internally powered Profibus
- ODVA compliant DeviceNet
MM300-GEHDSCABD Specifics
- The MM300-GEHDSCABD unit is equipped with a standard DeviceNet Slave 10/100 Modbus TCP.
- It includes physical ports for both USB and Ethernet connections.
- This model features two 10 amp form A relays and six digital inputs
Frequently Asked Questions about MM300-GEHDSCABD
What does the “G” in the model number stand for? What capabilities does this element offer the unit?
The “G” in the model number of GE Multilin’s MM300-GEHDSCABD indicates that it comes with a graphical control panel, which allows the user to interface with the relay with pushbuttons and a liquid-crystal display. It provides all available settings options and system information in an intuitive, easy-to-navigate menu. The LCD is a 3.5-inch 240 by 320 pixel screen. It provides a summary of the machine’s status. The data is efficiently laid out and accompanied by a number of keys that make navigating the screen intuitive and simple. The “G” in the model number contrasts with options “B” and “X”. “B” indicates a basic control panel that has neither the USB connection or the liquid-crystal display, but does include a small array of pushbuttons and LED indicators. The “X” option, on the other hand, includes no control panel whatsoever.
What programming software does the MM300-GEHDSCABD use?
This unit runs on the FlexLogic programming software.
