About the 350-E-P5-GS-H-E-E-N-N-SN-D-H
Overview
The 350-EP5GSHEENNSNDH is a feeder protection relay from Multilin’s 350 series. This model offers certain advanced features that set it apart from the baseline such as its current protections. This series was made to control, manage, and protect feeder applications in industrial and utility environments. This protection may be either primary or backup in these low, medium, or high-voltage applications.
Highlighted Features
The 350-EP5GSHEENNSNDH has extended current protections which include features like phase/neutral/ground time/instantaneous overcurrent and thermal overload. This model is coated in harsh environment conformal coating to help protect sensitive components from hazards like dust, corrosion, humidity, etc. This model uses the drawout case design which reduces potential system downtime in an effort to be more cost-effective and convenient than a non-drawout model.
Standard Features
The 350-EP5GSHEENNSNDH has 5A ground and three-phase current inputs as well as 10 contact inputs and 7 outputs. These outputs consist of 2 Form A outputs and 5 Form C outputs. This model supports RS485 and USB ports as well as Modbus RTU, DNP3.0, and IEC 60870-5-103 protocols for communication with existing systems. Control features of this model include lockout relay and cold load pickup. The front panel of this unit is rated at an IP54 level of ingress protection.
