About the 350-E-P5-S5-H-E-E-N-M-1E-D-N
General
The 350-EP5S5HEENM1EDN is a 350 series model of feeder protection system from GE Multilin. The purpose of this unit is to protect, manage, and control industrial or utility feeder systems. This unit uses a high-voltage 125-250VDC/120-240VAC power supply. Certain features on this unit are advanced while others may be more basic. For example, this model uses a drawout case design to reduce downtime, but it lacks harsh environment conformal coating.
Advanced Functionality
The 350-EP5S5HEENM1EDN has advanced communications, current protections, and metering capabilities. This unit has USB, RS485, and Ethernet connectivity along with support for protocols like IEC 60870-5-104, DNP3.0, Modbus TCP/IP, and more. The extended current protections on this model include things like thermal overload, phase/ground/neutral instantaneous overcurrent, and phase/ground/neutral time overcurrent. This model comes with energy, power, and voltage metering functionality.
Technical Information
The 350-EP5S5HEENM1EDN has cold load pickup and lockout relay control features. This unit has 10 contact inputs, 2 Form A outputs, and 5 Form C outputs. The three-phase current inputs and sensitive ground input are 5A on this model. This unit is rated for an ambient operating temperature between -40°C and 60°C and a humidity level of up to 95% at 55°C.
Frequently Asked Questions about 350-E-P5-S5-H-E-E-N-M-1E-D-N
Does the 350-EP5S5HEENM1EDN include CT supervision?
What kind of security features are present in the 350-EP5S5HEENM1EDN?
