About the 469-P5-HI-A20-E-H
GE Multilin 469-P5-HI-A20-E-H Motor Management Relay:
- Type: Microprocessor-based Motor Management Relay.
- Purpose: Designed for protecting and managing medium and large HP motors and equipment.
- Availability: An example of a Multilin motor protection relay; other options are available in stock.
Capabilities & Specifications
- Outputs: Features six output relays for start blocks, alarms, or trips.
- Functions: Handles fault diagnostics, power metering, motor protection, and RTU functions.
- Diagnostics: Diagnostics are provided through event records, statistics, trace memory, and pre-trip data.
- CT Secondaries: Basic relay unit with 5A phase CT secondaries.
- Power Ratings: Rated for 90-300 VDC or 70-265 VAC @ 48-62 Hz.
- Analog Outputs: Provides 4-20 mA analog outputs.
Physical Design & Interface
- Case Design: Uses a fixed case and draw-out unit for mechanical protection.
- Ventilation & Cleaning: No special ventilation required; can be cleaned with a damp cloth.
- Mounting: Can be used in a single or double cutout panel.
- Front Panel:
- Display: Features a 40-character display.
- LED Indicators: Three groups of LED indicators for 469 status, Motor Status, and output relay status.
- Controls: Includes a programming port, a numerical keypad, and eight additional buttons.
Documentation & Safety
- Refer to GE Documentation: For detailed information, consult original GE data sheets and manuals for the 469 series.
- Installation & Handling: Read and understand all installation and handling instructions from GE manuals before unboxing to ensure safety and product longevity.
Frequently Asked Questions about 469-P5-HI-A20-E-H
Where can I find the data on the motor speed for the GE 469-P5-HI-A20-E-H Motor Management Relay?
The data for the “Motor Speed” of the 469-P5-HI-A20-E-H Motor Management Relay is in the main menu in the “Actual Values” tab, the “Metering Data” tab in the “Actual Values” menu is where you can find “Motor Speed”.
Does this GE Motor Management Relay 469-P5-HI-A20-E-H record and save data?
Yes, some data is stored in the GE Motor Management Relay, this data can be found in the main menu of the display screen. You can locate information in the menu, depending on what you are trying to find information on. The manual for the GE Motor Management Relay can help with the navigation through the main menu and the manual for this relay can be found with the manual part number 1601-0122-A9.
Can settings be changed or updated in the stored data of the GE 469-P5-HI-A20-E-H Relay?
Settings that are stored in the Relay are saved immediately after entered into the relay. Settings can be updated and changed, but use caution while changing settings while the motor relay is on or in service. This action can cause a lack of coordination with the data that was saved before changes are made, incompatibility with the data before might cause unwanted operation. Unauthorized modifications to the settings can be stopped by security protection with a password and hardware features. Programming a pass code that has at least eight characters can help with this security feature, the factory passcode that is defaulted to the relay is always “0”.
