GE Multilin G60 G6F00HFH6CM8FP6PU6CWXX Generator Protection Relay

Overview
The GE Multilin G60 is a generator protection relay designed for medium and large generators. It offers advanced protection, monitoring, and control to ensure safe and efficient operation in industrial power systems.
Technical Specifications
General Information
◦ Manufacturer: General Electric (GE)
◦ Series: Multilin G60
◦ Product Type: Generator Protection Relay
◦ Application: Steam, gas, and hydro turbines
Electrical Specifications
◦ Power Supply: 24V DC or 110-240V AC
◦ Protection Functions:
◦ Overcurrent and differential protection
◦ Loss of excitation and reverse power detection
◦ Voltage and frequency monitoring
◦ Synchronization checks
◦ Relay Outputs: Configurable for control applications
Communication & Connectivity
◦ Supported Protocols: Modbus, DNP3, IEC 61850
◦ Data Logging: Event recording and fault analysis
◦ Human-Machine Interface (HMI): LCD display for real-time monitoring
Environmental Specifications
◦ Operating Temperature Range: -40°C to +70°C
◦ Humidity: 10% to 95% RH, non-condensing
◦ Shock & Vibration Resistance: IEC 60068 compliant

The G60 is designed for various power applications, including autotransformers, generator step-up transformers, split-phase, angle regulating transformers and reactors. It uses multiple current and voltage inputs to provide primary protection and backup protection of transformers, including differential, ground differential, five distance zones, phase, neutral, and ground overcurrent, under and overvoltage, under and overfrequency, over-fluxing, and breaker failure.

Key Benefits

• Secure high-speed protection for transformers, compliant with IEEE C37.91
• Advanced IEC 61850 Ed. 1 and Ed. 2 certified implementation, complete settings via SCL files and flexible process bus support (IEC 61850-9-2LE, IEC 61869 or IEC 61850-9-2 Hardfiber) ensures interoperability, device managing optimization and reduced cost of ownership
• Routable GOOSE (R-GOOSE) enables GOOSE messages going beyond the substation, which enables wide area protection and control applications
• Improved security for transformer energization and inrush provided through an adaptive 2nd harmonic restraint algorithm and an independent harmonic detection element
• Three independent fiber or copper Ethernet ports for simultaneous/dedicated network connections with advanced 1 microsecond time synchronization via LAN with IEEE 1588 support
• Sensitive ground fault protection provides low- impedance differential protection down to 5% of the winding to limit transformer damage
• Phasor Measurement Unit (synchrophasor) according to IEEE C37.118 (2014) and IEC 61850-90-5 support
• Advance Cyber security features “CyberSentryTM” that helps meet modern industry requirements
• Application flexibility with multiple I/O options including high density I/O, programmable logic, modularity, and specific customization
• An integrated large, full color display, provides real-time visualization and control of the protected bay, via a bay mimic as well as annunciator functionality and graphical visualization of phasors

Applications

• Transformer asset monitoring using loss-of-life, aging factor, hottest spot
• Applicable for transformers with up to six windings in a ring bus or breaker-and-a-half configuration
• Reliable and secure protection for three-phase transformers, autotransformers, reactors, split-phase and phase angle regulating transformers
• Stand-alone or component in automated substation control system
