GE SR745-W2-P1-G1-HI-E-H Industrial Transformer Management System – Precision Monitoring & Protection Solution
Engineered for mission-critical transformer management, the GE SR745-W2-P1-G1-HI-E-H delivers advanced protection and control for transformers, autotransformers, and reactors. This industrial-grade system combines intuitive operation with robust hardware, featuring a 40-character LCD for clear data visualization and an expanded keypad for rapid setpoint adjustments. Designed for seamless integration into demanding environments, it ensures operational reliability while minimizing downtime through real-time status alerts.
Key Features
- Enhanced 40-Character LCD Display – Provides clear visibility of critical parameters and diagnostics.
- Expanded Keypad Interface – Simplifies manual configuration and setpoint adjustments.
- Compact 19-Inch Panel Mount Design – Fits standard industrial control panels with dimensions 9”H x 7”W x 7 ⅛”D.
- Real-Time LED Alerts – Visual indicators for fault detection and operational status monitoring.
- High-Voltage Capability – Supports up to 273 V continuous output for demanding applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand/Model | GE SR745-W2-P1-G1-HI-E-H |
| Power Requirements | 90–300 V DC; 70–265 V AC (48–62 Hz) |
| Dimensions & Weight | 9”H x 7”W x 7 ⅛”D |
| Signal I/O Types | RTD Inputs: 3-wire, 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum Analog Output: 0–1 mA / 4–20 mA (Max Load: 10 kΩ at 0–1 mA, 600 Ω at 4–20 mA) |
| Max Voltage Output | 273 V |
| Installation Method | 19-inch Panel Mount |
Application Fields
Engineered for critical infrastructure applications, this system excels in power generation facilities, electrical transmission networks, industrial manufacturing plants, oil & gas processing, and renewable energy installations. Its precision monitoring capabilities ensure optimal transformer performance in environments requiring continuous uptime and compliance with stringent safety standards.
