GE SR750-P5-G1-S1-HI-A20-R: Advanced Feeder Management Relay for Industrial Power Systems
The GE SR750-P5-G1-S1-HI-A20-R is a high-performance feeder management relay engineered to deliver precision protection and control in industrial distribution networks. Featuring multi-layered protection algorithms, real-time waveform capture, and dual-protocol communication, this relay ensures optimal system reliability in critical infrastructure applications.
Key Features
- Comprehensive Protection: Integrates overcurrent, under/overfrequency, and ground fault protection with adjustable 0-1.25×VT pickup levels
- High-Speed Communication: Supports Modbus RTU and DNP 3.0 protocols with 300-19200 baud rate flexibility
- Advanced Monitoring: Captures 4 current channels, 3 voltage channels, 14 logic inputs, and 8 output relays simultaneously
- Compact Design: Space-saving 18cm W × 16.5cm L × 21.5cm H enclosure for standard 19-inch panel installations
- Waveform Analysis: Enables detailed fault analysis through EnerVista 750 software integration
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand/Model | GE SR750-P5-G1-S1-HI-A20-R |
| Current Inputs | 5A phase, 1A zero sequence |
| Voltage Inputs | Sensitive ground current detection |
| Operating Environment | Up to 90% RH non-condensing |
| Communication | Modbus RTU/DNP 3.0 |
Application Fields
Engineered for demanding industrial environments, this relay excels in:
- Power generation and distribution systems
- Manufacturing plant electrical networks
- Utility substation automation
- Commercial building energy management
- Renewable energy integration systems
This product is part of our premium inventory featuring leading industrial control brands including ABB (DSQC series, PM866), Triconex (3008, 3703X), Woodward (UG-10D, 8440-1713/D), and Emerson Epro solutions. Our inventory guarantees rapid delivery of certified genuine components with full technical support.
