GE VME5565 VMIVME-5565-11000 332-015565-110000 P Reflective memory node card

Describtion：

VMIVME-5565-11000 is the Mark VI series ISBB bypass module developed by General Electric Company. General Electric has developed the Mark VI system to manage steam and gas turbines. Mark VI operates this operation through central management, using a central control module with a 13 or 21-slot card holder, which is connected to the terminal board that introduces data from the surrounding system. And Mark VIe follows the central management direction through distributed management (DCS – Distributed Control System) by placing control nodes throughout the system. Both of these systems are designed to be compatible with integrated software such as the CIMPLICITY graphics platform.

Characteristics

This component is installed in a rectangular housing with four inputs or outputs. Two of them are located at the bottom of the device and two are located at the top of the device.

Two female sockets are placed side by side on the top of the equipment. One of them (P2) is marked with “Transmission Output”. The other one (P3) says “receive”. The additional female jack marked “Full duplex” (P1) and the two-position terminal board marked 10 mA Max 24 V DC (TB1) are located at the bottom of the device. The openings at the top and bottom of the equipment facilitate air circulation and heat dissipation.

There are two LED status indicator lights on the front of this module. Receiver activity and unbypassed are this tag. The rear design of this device allows users to choose the installation method. On the side of the device, there are labels for each module connector (top and bottom) as well as charts to help solve the LED problems on the front panel.

The GE VMIVME-5565-110000 is a multifunctional and high-performance VMEbus board, specifically designed for industrial and embedded computing applications. It offers advanced features and functions to meet the demands of complex data acquisition and processing tasks.

Function:
The network transmission rate ranges from 43 Mbyte/s (4-byte data packets) to 170 Mbyte/s (64-byte data packets).
Dynamic data packet size, 4 to 64 bytes of data
Up to 256 nodes
The connection with multimode optical fibers can reach up to 300 meters at most, and the connection with single-mode optical fibers can reach up to 10 kilometers at most
The data written to the memory of one node will also be written to the memory of all nodes on the network
High-speed and easy-to-use optical fiber network (serial rate 2.12 Gbaud)
The.vme transmission rate is 40 Mbytes
64 Mbyte or 128 Mbyte SDRAM reflected memory
