GE VMIVME-7698 VME bus single-board computer

product description

VMIVME-7698 is a high-performance VME bus single board computer with a wide range of applications, including data acquisition and control, signal processing, image and video processing, automation and control systems, as well as testing and measurement. It is based on the Intel Pentium 1 processor, with a clock speed of up to 1.26 GHz, supports up to 2GB of DDR SDRAM, and has two PMC sites for additional I/O expansion. In addition, it is equipped with two Gigabit Ethernet ports, four USB 2.0 ports, and two serial ports, providing rich communication interfaces.

As a VME bus module, VMIVME-7698 has a standard VME bus interface, which can be easily integrated into existing VME systems and achieve seamless connection with other VME devices. To meet the needs of military and aerospace fields, VMIVME-7698 typically has a wide temperature operating range and can operate normally under extreme temperature conditions. Meanwhile, it may adopt advanced cooling design, redundant power supply and other reliability measures to ensure stable operation in harsh environments.

The design of VMIVME-7698 also includes some special features, such as a selectable memory format of up to 512 megabytes and up to 3 programmable 16 bit timer modules. In addition, it also has a 32 kilobyte battery supporting SRAM memory, can support remote Ethernet connection booting, and has a software selectable watchdog timer with reset function.

Overall, VMIVME-7698 is a powerful and stable VME bus single board computer, suitable for various industrial applications that require high performance and reliability. However, in order to ensure the stability and reliability of modules during continuous high load operation, manufacturers often adopt efficient heat dissipation designs, which may increase their costs. When selecting and using, it is necessary to comprehensively consider the actual application needs and environmental conditions.

Functional Features

High Reliability:
Stable operation within an extreme temperature range of -40°C to +85°C, adaptable to various harsh environments.
Compliant with MIL-STD-810G standards, featuring high resistance to vibration and shock.
Rich I/O Interfaces:
Equipped with multiple interfaces to meet the demands of diverse application scenarios.
Powerful Computing Capability:
Fitted with high-performance processors and large-capacity memory, providing the system with strong computing power and efficient data processing performance.
Easy Maintenance:
Adopting a single-board design, integrating processors, memory, input/output interfaces, and other components, facilitating maintenance and upgrades.

Application fields
Industrial automation:
With high-performance computing capabilities and rich I/O interfaces, it is an ideal choice for industrial control, data acquisition and monitoring systems.
Military and aerospace:
It is widely used in key areas such as military communication, radar systems, and flight control.
Traffic control:
In intelligent transportation systems, it is used for traffic signal control, video surveillance and analysis, vehicle identification and other applications, improving traffic management efficiency.
Medical equipment:
It is suitable for medical equipment with high requirements for computing performance and stability, such as medical image processing and patient monitoring systems, contributing to the informatization development of the medical industry.
