Description
The GE Fanuc DS200GDPAG1ALF is a High Frequency Power Supply Board designed for GE’s Mark V Series turbine control systems. Part of the Mark V Speedtronic series, this board is engineered to efficiently manage and control industrial gas and steam turbines, ensuring optimal performance and reliability.
Key Features:
- AC and DC Power Measurement: Measures both AC and DC input power, with built-in current-limiting action to prevent power surges.
- High-Frequency Conversion: Includes a 27 kHz inverter, converting DC to high-frequency AC, ideal for turbine systems requiring precision power management.
- Stable Power Supply: Provides 120 V DC power supply, delivering a steady and reliable DC voltage to the system.
- Protective Circuits: Detects and mitigates faults, ensuring protection for the power supply and connected components.
al Specifications:
| Parameter | Description |
|---|---|
| Manufacturer | General Electric (GE) |
| Part Number | DS200GDPAG1ALF |
| Product Type | High Frequency Power Supply Board |
| Functional Description | Measures AC and DC input power with current limiting action. |
| Input Rectifier and Filter | Converts and filters incoming power for smooth operation. |
| Regulator (Buck Chopper) | Maintains consistent voltage levels throughout the system. |
| 27 kHz Inverter | Converts DC power to high-frequency AC for turbine control. |
| Output Transformer | Provides 50 volts AC for system operations. |
| 120 V DC Power Supply | Supplies stable 120 V DC to power system components. |
| Control Power Supply | Powers control circuits and supports system operations. |
| Control Signal Level Circuits | Processes control signals for the turbine control system. |
| Protective Circuits | Detects faults and mitigates potential risks to the system. |
| Weight | Not specified, generally lightweight for turbine control components. |
