Description
The GE Fanuc DS200PTBAG1AEC is a Termination Board designed specifically for the Speedtronic Mark V gas turbine control system. This board centralizes the connections for field wiring, ensuring efficient, reliable, and organized communication within the turbine control system. Built for industrial environments, it supports the robust demands of turbine control in power generation and automation.
Key Features:
- Centralized Connectivity: Streamlines field wiring for easy and organized connections.
- High Reliability: Engineered for durability and long-lasting performance in demanding industrial applications.
- Signal Wire Connections: Equipped with multiple posts for expanded wiring options and flexibility.
Technical Specifications:
| Parameter | Description |
|---|---|
| Manufacturer | General Electric (GE) |
| Part Number | DS200PTBAG1AEC |
| Product Type | Termination Board |
| Terminal Blocks | Two blocks, each with 72 terminals for signal wires. |
| Connectors | Three 10-pin connectors for easy integration with other components. |
| Signal Wire Terminal Posts | Six posts available for additional signal wire connections. |
| Dimensions | 3 inches high, 11.5 inches wide (approx. 7.62 cm x 29.21 cm). |
| Mounting Hole | One mounting hole for secure installation. |
| Country of Origin | USA |
