General Electric DS200TCQCG1BJF Printed Circuit Board

The GE Fanuc DS200TCQCG1BJF is a Printed Circuit Board (PCB) designed for use within the Mark V Turbine Control System Series. It serves to expand the analog input/output (I/O) capabilities of turbine control systems, enhancing their functionality and enabling better system integration.

Key Features:

• Product Type: Analog I/O Expander Board / RST Overflow Board
• Part Number: DS200TCQCG1BJF

Technical Specifications:

• Connectors:
  • 3 x 40-pin connectors (IDs: JFF, JE, 6PL)
  • 3 x 34-pin connectors (IDs: JFF, 1PL, JA)
  • 1 x 16-pin connector (ID: JC)
• Jumpers:
  • 24 total jumpers for configuration and functionality customization
• Relays:
  • Multiple relays for circuit switching, soldered and maintenance-free for improved reliability
• Ribbon Cable Connectivity:
  • Connects to other boards via ribbon cables, maintaining seamless functionality across the system
•
