Description
The GE DS200TCTLG1ABB is a specialized Turbine Reheat and Trip Control Board designed for GE Mark V Speedtronic™ turbine control systems. It plays a critical role in turbine protection, particularly for steam turbines, though it is also applicable for gas and wind turbines. This board integrates key turbine safety functions, including the master trip circuit, emergency trip relays, and auxiliary solenoid outputs, ensuring safe and reliable turbine operation.
Key Features:
- Model Number: DS200TCTLG1ABB
- Board Type: Turbine Reheat Trip Board
- System Compatibility: Compatible with GE Mark V Speedtronic™ systems
- Trip Relays:
- PTR1, PTR2 (primary)
- ETR1, ETR2, ETR3 (emergency)
- Solenoid Outputs:
- 4 auxiliary control outputs
- Test Modes Supported:
- Electrical overspeed, mechanical trip, emergency cross-trip, TMR cross-trip
- PCB Protection: Conformal coating for environmental durability
- Mounting: Rack-mounted in Mark V cabinet
Technical Specifications:
| Parameter | Specification |
|---|---|
| Dimensions | 186 mm × 110 mm × 124 mm |
| Weight | 2 kg |
| Operating Temperature | –30°C to +65°C |
| Certifications | UL, CE, IEC-compliant |
