General Electric IC670ALG240 Analog Input Current 16pt

The IC670ALG240 is a 16-point grouped analog current output module designed for the Genius Field Control system. This module facilitates the conversion of input signals from current transmitters into digital values for processing by the host processor, ensuring effective control and monitoring in industrial applications.

Key Features

• Manufacturer: GE Fanuc
• Product Type: Analog Current Output Module
• Series: Genius Field Control
• Number of Channels: 16 single-ended current loop inputs
• Input Compatibility: Accepts input from 2-wire and 3-wire current transmitters

Technical Specifications

• Current Output Range: 0 to 25 milliamps
• Signal Processing:
  • Converts input signals to digital values for the host processor
  • Scales signals according to set parameters and converts to engineering units
• Alarm Reporting:
  • High/Low alarms
  • Under/Over-range conditions
  • Open wire conditions
• Diagnostic Commands: Automatically triggered by error conditions for easy monitoring via the host processor

Electrical Characteristics

• Power Requirements:
  • Requires a 20 to 28 Volts DC external power supply for current loops
  • Does not require additional power supply for operation
• Filtering Types:
  • Input filter
  • Line filter
  • Averaging filter
• Scaling Options:
  • 3 predefined scale selections
  • User-configured custom scaling feature

Configuration and Installation

• Configuration Method: Configured via the Bus Interface Unit (BIU) using a handheld programmer
• Wiring Base: Installed on a terminal block for easy field wiring
• Replacement: Can be replaced from the terminal block without needing to reconfigure terminal wiring
•
