Description
The General Electric IS200DSPXH1DBD is a high-performance Digital Signal Processor (DSP) Control Board developed for the Mark VI Speedtronic control system. It is specifically designed to enhance the processing power of control systems used in gas and steam turbines. The board is also compatible with Innovation Series drives and EX2100 excitation systems.
Key Features & Specifications
- Manufacturer: General Electric (GE)
- Part Number: IS200DSPXH1DBD
- Functional Abbreviation: DSPX
- Product Type: Digital Signal Processor Control Board
- Product Series: Mark VI Speedtronic
- Product Origin: USA
- Weight: 350g
Product Overview
The IS200DSPXH1DBD is a significant advancement over its predecessors, including the Mark V Turbine Control System. As part of the Mark VI Speedtronic series, it provides broader application support and improved flexibility, especially in wind turbine environments, while retaining full backward compatibility for traditional gas and steam turbines.
It is one of the final generations of turbine control systems to integrate GE’s Speedtronic technology, which offers enhanced diagnostic capabilities, real-time control, and flexible I/O configurations. This makes the IS200DSPXH1DBD ideal for both modern and legacy turbine applications.
Revision History & Compatibility
- Total Revisions: 3 revisions
- Functional Revisions: D and B
- Artwork Revision: D
- Backwards Compatibility: Compatible with the first two revisions
Assembly Details
- Assembly Type: Normal Assembly
Applications
The IS200DSPXH1DBD is commonly used in the following applications:
- Gas and Steam Turbines
- Wind Turbine Systems
- Innovation Series Drives
- EX2100 Excitation Systems
