Description
The IS200EGDMH1ADE is a Ground Detector Module from General Electric, specifically designed for the EX2100 Series Excitation Control Systems. It plays a critical role in monitoring the excitation system for ground faults. This module ensures the system’s reliability by detecting any ground fault conditions, which is essential for maintaining optimal performance and safety.
Key Features:
- Ground Fault Detection: Actively monitors and detects ground faults in excitation systems.
- Integration with EX2100 Series: Seamlessly integrates with GE’s EX2100 Excitation Control System for enhanced system management.
- Real-Time Monitoring: Provides real-time feedback on system status, enhancing operational safety.
- LED Indicators: Equipped with LEDs to display fault status and operational health.
- Compact Design: Space-efficient module suitable for various industrial control environments.
- Durability: Built to endure industrial environments, offering long-lasting reliability.
Technical Specifications:
| Parameter | Specification |
|---|---|
| Model Number | IS200EGDMH1ADE |
| Type | Exciter Ground Detector Module |
| Series | EX2100 Excitation Control System |
| Voltage Range | 24 VDC |
| Power Consumption | Low power consumption for efficiency |
| Input Voltage | 24 VDC |
| Output Voltage | 5 VDC |
| Ground Fault Detection Range | Up to 1000 Ohms |
| LED Indicators | Two LEDs for operational status |
| Weight | 0.75 kg (approx. 1.65 lbs) |
| Environmental Protection | Designed to operate in harsh conditions |
| Operating Temperature | -40°C to 85°C (-40°F to 185°F) |
Installation and Usage:
- Integration: The IS200EGDMH1ADE integrates easily into the EX2100 system, ensuring reliable ground fault detection within the excitation control system.
- LED Indicators: The module features LED indicators for clear fault detection, allowing operators to quickly identify and resolve issues.
- Compact Design: Its compact size makes it ideal for tight spaces, ensuring hassle-free installation in most industrial settings.
