General Electric IS200VAICH1DAA VAIC Analog Input/Output Board

The GE Fanuc IS200VAICH1DAA VAIC Analog Input/Output Board is a crucial part of the Mark VI system, designed for controlling and monitoring inputs and outputs in industrial applications. This board supports higher load resistances for 20 mA output drive voltage, providing up to 18 V at the terminal board’s screw terminals.

Technical Specifications:

• Part Number: IS200VAICH1DAA
• Series: Mark VI
• Manufacturer: General Electric Company USA, GE Industrial Systems
• Product Type: Analog Input/Output Board
• Functional Acronym: VAIC
• Number of Analog Inputs: 20
• Number of Analog Outputs: 4
• Location: VME Rack
• Analog Output Circuits Range:
  • 4-20 mA
  • 0-200 mA
• Diagnostic Checks:
  Includes up to five different checks, such as monitoring D/A outputs and current scaling.
• Terminal Boards Compatibility:
  Compatible with TBAIH1C or any revision of STAI.
• System Application:
  Usable in both simplex and triple modular redundant (TMR) systems.
•

• Key Features:

  • Product Type: Analog I/O Expander Board / RST Overflow Board
  • Part Number: DS200TCQCG1BJF

  Technical Specifications:

  • Connectors:
    • 3 x 40-pin connectors (IDs: JFF, JE, 6PL)
    • 3 x 34-pin connectors (IDs: JFF, 1PL, JA)
    • 1 x 16-pin connector (ID: JC)
  • Jumpers:
    • 24 total jumpers for configuration and functionality customization
  • Relays:
    • Multiple relays for circuit switching, soldered and maintenance-free for improved reliability
  • Ribbon Cable Connectivity:
    • Connects to other boards via ribbon cables, maintaining seamless functionality across the system
