Description
The IS215RCLEH1BC is a modular assembly from General Electric, designed specifically for the EX2100 or EX2100E Excitation Control System Series. This microprocessor-based controller manages communication over networks like ISBus and Ethernet. The module is designed to occupy two half-slots in the EX2100 exciter board rack and is equipped with specialized hardware components, including capacitors, resistors, transistors, diodes, and integrated circuits (ICs). The IS215RCLEH1BC supports non-volatile flash memory for storing application configurations, and includes LEDs, a CPU, and a PCI controller for efficient management.
Features:
- Microprocessor-Based Controller: Manages communication through ISBus and Ethernet.
- Slot Compatibility: Occupies two half-slots in the EX2100 exciter board rack.
- Specialized Hardware: Includes capacitors, resistors, transistors, diodes, and ICs for robust performance.
- Status Indicators: Equipped with LEDs, CPU, and a PCI controller for efficient I/O management and monitoring.
- Non-Volatile Flash Memory: Stores application configurations to ensure system consistency.
- Ethernet Connectivity: 10BaseT/RJ45 jack on the front panel for network communication.
- L2 Cache: 128 KB for efficient data processing.
- Environmental Protection: Conformal PCB coating to protect against external factors.
- Software Features: Supports BIOS, I/O points, internal booleans forcing, and online configuration loading.
- Integration with Innovation Series Drives: Supports application control for Innovation Series drives.
Technical Specifications:
| Parameter | Specification |
|---|---|
| Model Number | IS215RCLEH1BC |
| Functional Acronym/Abbreviation | ACLE (Application Control Layer) |
| Series | EX2100 Excitation Controller |
| Group and Functional Revision | H1B |
| Potential Added Component | PROM |
| Weight | 1 lbs 4 oz (1.25 lbs) |
| Shipping Dimensions | 18 x 12 x 12 inches |
| Country of Origin | United States (USA) |
| Cache Level | Level 2, 128 KB |
| Flash Memory | Non-volatile, byte mode access |
| Ethernet Connection | 10BaseT/RJ45, IRQ 5 initialized by BIOS |
| PCI Controller | Manages I/O, configuration, and memory functions |
| Voltage Suppression and Limitation | Standardized components: capacitors, resistors, transistors, diodes, ICs |
| Conformal PCB Coating | Provides environmental protection |
| I/O Points and Internal Booleans | Flexible control and monitoring |
| Application Control for Innovation Series Drives | Integration with GE’s drive systems |
| Online Application Configuration Loading | Allows dynamic updates and adjustments |
| Control Block | Coordinates system operation and control |
Applications and Benefits:
The IS215RCLEH1BC Application Control Layer Module is a critical component for EX2100 Excitation Control Systems. It provides efficient management of input/output operations and data transfers, while maintaining system stability and performance through flexible and customizable configurations. It is ideal for environments that require real-time application loading, integration with Innovation Series Drives, and robust data handling capabilities.
- Industrial Applications: Suitable for power generation systems, turbine control, and other industrial automation systems.
- Seamless Integration: Easily integrates with GE’s EX2100 exciter systems, making it a valuable component for upgrading or maintaining system performance.
-
