About the 350-C-P5-G1-H-S-M-N-P-SN-D-N
Introduction
The 350-CP5G1HSMNPSNDN is a feeder protection system from GE Multilin’s 350 series. This model was built to provide protection, control, and management of industrial and utility feeders. This unit may serve as primary or backup protection in these systems. This series was designed to work with low, medium, and high voltage feeder systems. This unit has a particular configuration of optional features that suit it for specific scenarios.
Relay Features
The 350-CP5G1HSMNPSNDN has a high-voltage power supply that operates between 125-250VDC/120-240VAC. This model has the standard array of inputs and outputs. This unit has 8 contact inputs and 7 outputs. 2 of these outputs are Form A and 5 are Form C. This unit has a drawout case design to simplify maintenance, installation, and testing processes. This unit does not have harsh environment conformal coating, so it is better suited for less extreme environments.
Protection Features
The 350-CP5G1HSMNPSNDN has advanced voltage and current protections. The voltage protections include useful functions like phase/auxiliary undervoltage, overvoltage, over frequency, and more. This unit also comes with voltage, power, and energy metering capabilities. The current protections on this model include all the extended features along with negative sequence time/instantaneous overcurrent and broken conductor.
