About the 350-C-P5-G5-H-E-M-N-P-SN-D-N
General
The 350-CP5G5HEMNPSNDN is a 350 series feeder protection system from GE Multilin. This model is designed to provide management, control, and protection to low, medium, and high-voltage feeder systems in both industrial and utility applications. This unit comes with a host of optional features that improve functionality in certain areas like current/voltage protection.
Unit Protections
The 350-CP5G5HEMNPSNDN has the most advanced current protection package available to the 350 series. This includes all the basic and extended protections along with negative sequence instantaneous/time overcurrent and broken conductor. The control package on this unit includes cold load pickup and lockout relay features. This unit also has the advanced protection package, which includes useful functions like directional power relay, phase/auxiliary undervoltage, overvoltage, and over frequency as well as voltage, power, and energy metering capabilities.
Miscellaneous Features
The 350-CP5G5HEMNPSNDN has 5A ground and three-phase current inputs. Additionally, this unit has 10 contact inputs and 7 outputs, of which 2 are Form A and 5 are Form C. This model uses a 125-250VDC/120-240VAC high-voltage power supply. The case for this unit uses the drawout design to allow easier access to internal parts for testing, maintenance, etc. This unit has standard communication features, which include a front USB port, rear RS485 port, and support for various protocols like Modbus RTU and DNP3.0.
Frequently Asked Questions about 350-C-P5-G5-H-E-M-N-P-SN-D-N
What kind of setup software does the 350-CP5G5HEMNPSNDN use?
What humidity level is the 350-CP5G5HEMNPSNDN rated for?
