About the 350-E-P1-G1-H-E-S-N-M-3E-D-N
General
The 350-EP1G1HESNM3EDN is an advanced feeder protection system in the 350 system from GE Multilin. This model comes with several advanced features that set it apart from the baseline in this series. This model combines feeder management, protection, monitoring, and control functionalities into one unit. This model was designed to be cost-effective and able to communicate with many existing systems.
Improved Features
Some of the advanced features on the 350-EP1G1HESNM3EDN include communications, metering, and case design. The advanced communications package adds copper/fiber Ethernet and support for IEC 61850, IEC 60870-5-104, Modbus TCP/IP, and DNP3.0 protocols. This unit has CT supervision as well as metering capability for power, energy, and voltage. This model has a drawout case, which simplifies processes that require the user to access the internal components of the relay.
More Information
As a high-voltage model, the 350-EP1G1HESNM3EDN uses a 120-240VAC/125-250VDC power supply. This model uses 1A current inputs for ground and three-phase currents. This unit comes with the series-standard control features of lockout relay and cold load pickup. The current protections on this model include phase/neutral/ground instantaneous overcurrent and phase/neutral/ground time overcurrent. This model is not coated in harsh environment conformal coating.
