About the 350-E-P5-G5-H-E-E-N-M-1E-D-N
Summary
The 350-EP5G5HEENM1EDN is a feeder protection system from GE Multilin. This model has advanced features in certain areas and more baseline features in others. For example, this model has the extended current protection feature set, but it lacks harsh environment conformal coating. This unit was made to provide primary or backup protection as well as control and management to low, medium, or high-voltage feeder applications.
Unit Strengths
The 350-EP5G5HEENM1EDN has advanced features when it comes to current protection, metering, and communication. This model offers protections like phase/neutral/ground time overcurrent, phase/neutral/ground instantaneous overcurrent, thermal overload, and more. Additionally, this model has power, voltage, and energy metering functionality. This unit supports copper and fiber Ethernet along with RS485 and USB ports for communications along with IEC 60870-5-104, Modbus TCP/IP, DNP3.0, and more protocols.
Additional Features
The 350-EP5G5HEENM1EDN uses a high-voltage 125-250VDC/120-240VAC power supply. This model has ground and three-phase current inputs of 5A and 10 contact inputs. This unit has a drawout case which serves to minimize costly system downtime by making internal components easier to access. This unit has lockout relay and cold load pickup control features which are standard to the series.
