Description
FSC 10201/2/1 Fail-Safe Digitial Input Module 24VDC 8 Channel
Model Type: 11501
Digital Output Module
Manufacturers:Honeywell
Model(s): Honeywell FSC
Additional Information: SUPPLY 5VDC 25MA; OUTPUT 24VDC 8 CHANNELS MAX 550MA
Dimensions: 2.5 x 20.3 x 15.2 cm
Weight: 0.2kg
Safety Manager Diagnostics
Safety Manager continuous self-tests enable the system to collect valuable information on the diagnostic status of its own hardware and the field equipment. The system uses this information to ensure the uninterrupted functional safety of the plant. In addition, the system provides the diagnostic information to the user, via the diagnostic displays of Safety Builder. Through its diagnostics, Safety Manager supports maintenance engineers in allocating and resolving failures effectively, thus reducing the Mean Time To Repair (MTTR) and minimizing the risk of a plant trip.
Control Processor The Control Processor (CP) is the heart of the SM controller. It is a modular microprocessor system specifically designed for safety-critical applications and can be tailored to the requirements of many applications. The main Control Processor modules are: • Quad Processor Pack (QPP) • Universal Safety Interface (USI) • Power Supply Unit (PSU) The Control Processor modules are constructed on a European standard size instrument card. The height of the front panel of the modules is 4 HE (4U), their width is 8 TE (8 HP) (USI, SMM, PSU, and BKM module), and the QPP module is 16 TE wide. The Control Processor modules are placed in the CP Chassis (19″ chassis), which are generally located in the top section of the cabinet.
Related Parts of Honeywell
10018/E/1 10201/2/1 10105/2/1 10020/1/2 10024/H/F 10101/2/1 10300/1/1 10102/2/1 10006/2/1 10215/2/1 10300/1/1 10024/I/I 10105/2/1 10018//E/110018/2/U 10018/E/E 10012/1/2 10215/2/1 10020/1/and 10020/1/2 10002/1/210012/1/2 10020/1/2 10020/1/1 10002/1/2 10012/1/2 10001/1/1 10001/R/1 10002/1/2 10012/1/210005/1/1 10007/1/1 10100/1/1 10101/1/1 10101/1/2 10101/2/2 10101/2/1 10105/2/1 10209/2/1 10001/R/1 10005/1/1 10006/2/1 10020/1/1 10018/E/1 10024/H/F
10300/1/1 10100/2/1 10101/2/1 10105/2/1 10303/1/1
