Description
HPMM Functionality
The HPMM provides the following functions:
•Communications with the Local Control Network (LCN) Network Interface Module (NIM) through the Universal Control Network (UCN)
•A Communications processor ( Motorola 68LC040)
•Communications through the I/O Link Interface with Input/Output Processors (IOPs) and I/O Link Extenders
•A Control processor (Motorola 68040)
•Separate and shared memory for the Communications and Control processors
•An I/O Link processor (Intel 80C32) with SRAM
•HPMM redundancy control
LLMUX2 FTAs Specifications
| Input channels | 16 fully-isolated channel-to-channel, channel-to-PM, and channel-to-power supply common |
| Input scan rate | 1 Second fixed by IOLP |
| Channel bandwidth | 0 to 4.7 Hz (-3 dB) |
| Nominal input range | -20 to +100 millivolts |
| Input impedance | 1 megohm at dc |
| Voltage | +/-250 Vdc or Vac RMS |
| Crosstalk | 80 dB (120 dB at 50 and 60 Hz) |
| Power dissipation | 2.25 watts max |
| Supported millivolt types | -20 to +100 millivolts |
Honeywell DCS Products
TC-CCN013 CNI Module, Single Media
TC-CCR013 CNI Module, Redundant Media
TC-CCR014 CNI Module, Redundant Media(TC-CCR013)
TC-CEN021 Ethernet Interface Module, 10/100MB
TC-FPCXX2 120/240vac Pwr Supply
TC-FPDXX2 24Vvdc Pwr Supply
TC-FXX102 10 Slot Chassis, 13 Amp
TC-FXX132 13 Slot Chassis, 13 Amp
TC-FXX172 17 slot chassis, 13 amp
TC-IAH061 Analog Input 6pt Module, CIOM-A
TC-IAH161 AI 16 Module (single or 8diff.),CIOM-A
TC-IDD321 DC Input Module 24vdc 32pt, CIOM-A
TC-IDJ161 DC Input Module 24vdc 16pt(isolated.), CIOM-A
TC-IDW161 AC Input Module 220vac 16pt, CIOM-A
TC-IXL061 Thermocouple Input Module6pt, CIOM-A
TC-IXL062 Thermocouple Input Module6pt, CIOM-A
TC-IXR061 RTD Input Module 6pt, CIOM-A
TC-OAH061 Analog Output 6pt Mod (4-20MA)CIOM-A
TC-OAV061 Analog Output Module 6 pt(10V), CIOM-A
TC-OAV081 AO Module 8pt (4-20ma &10V), CIOM-A
TC-ODA161 AC Output Module 120/220vac16pt, CIOM-A
TC-ODD321 DC Output Module 24vdc 32 pt, CIOM-A
TC-ODJ161 DC Output Module 24vdc 16pt, CIOM-A
TC-ODK161 AC Output Module 120/220vac16pt, CIOM-A
TC-PCIC01 ControlNet Interface Card (PCI Bus)
TC-PCIC02 ControlNet Interface Module, PCI-bus
