The Honeywell CC-PAIH01 51405038-175 is a HART-ENABLED ANALOG INPUT MODULE designed for use with Honeywell’s Experion® PKS and other control systems. This module provides high-precision analog signal acquisition while supporting HART digital communication for smart field devices, making it ideal for process automation in industries such as oil & gas, chemical, and power generation.

Technical Specifications

Key Features

1. HART Communication Support Simultaneous analog signal (4-20mA) and HART digital communication

Supports HART 7 protocol for device configuration and diagnostics Multidrop mode capability (up to 15 devices per channel)

2. High-Accuracy Analog Input 16-bit resolution for precise measurement Supports 4-20mA, 0-20mA, and voltage inputs (configurable) ±0.1% accuracy for reliable process control

3. Channel Isolation & Noise Immunity Channel-to-channel isolation (1500 VAC) prevents signal interference

Advanced filtering for noise reduction in harsh environments

4. Hot-Swappable & Redundant Configuration Supports online replacement (hot-swap) for minimal downtime

Compatible with redundant systems for high availability

5. LED Diagnostics & Status Indication Per-channel LED indicators for signal status and faults Module health monitoring for predictive maintenance.

Honeywell Experion PKS, C300 series

Honeywell Process Solutions is a pioneer in automation control, instrumentation and services for the oil and gas;    refining;    energy;    pulp and paper;    industrial power generation;    chemicals and petrochemicals;    biofuels;    life sciences;    and metals, minerals and mining industries.    It is also a leader in providing software solutions and instrumentation that help manufacturers find value and competitive advantage in through Honeywell Connected Plant, Honeywell’s Industrial Internet of Things (IIoT) solution.    Process Solutions is part of Honeywell’s Performance Materials and Technologies strategic business group, which also includes Honeywell UOP a leading international supplier and licensor of process technology, catalysts, adsorbents, equipment, and consulting services to the petroleum refining, petrochemical, and gas processing industries.

————————————————————————————————————————————-

Honeywell is a Fortune 100 technology company that delivers industry-specific solutions that include aerospace products and services;    control technologies for buildings and industry;    and performance materials globally.

The C300PM employs Honeywell’s deterministic Control Execution Environment (CEE) to execute control strategies on a constant and predictable schedule. The CEE is loaded into the C300PM controller, providing the execution platform for a set of automatic control, logic, data acquisition and calculation function blocks.

The Experion PKS C300 controller forms the heart of the Experion control system, and is ideal for implementation across all industries, with best-in-class process control capabilities and security. It supports a wide variety of process control applications, including continuous and batch processes, and integration with smart field devices. The C300 controller also supports advanced process control, as well as custom algorithm blocks that let users create custom code to run in the C300 controller.

The C300 controller provides the means to overcome the increasing complexity of control systems, reduce Cyber risks and significantly improves the operational and lifecycle support aspects for control systems, as it offers :

• Robust and scalable Control Platform for a wide range of control applications addressing the most demanding process control requirements.
• A new paradigm for process control with IO & Control HIVE enabling maximum flexibility, scalability, standardization, optimization, and resiliency
• Best-in-class security ensuring safe and secure operations
• Facilitates modular and parallel project execution
• Maximized process uptime and minimized maintenance effort with robust diagnostics and innovative redundancy schemes
• Improved engineering productivity and maintenance using the rich function libraries provided in the intuitive user environment Seamless integration of smart field devices and controllers via standard protocols.
• FC-TSAI-1620m Safe AI FTA 0(4)-20mA 16-channel CC AI Terminal Board
  FC-TSDI-16UNI Safe DI FTA NAMUR, 16-channel CC DI Terminal Board
  FC-TSDI-1624C Safe current-limited DI FTA 24V, 16-channel CC DI Terminal Board
  FC-TSDI-16115 Safe active/passive DI FTA 115V, 16-channel CC DI Terminal Board
  FC-TIDI-1624 Isolated passive DI FTA 16-channel CC DI Terminal Board
  FC-TSAO-0220m Safe AO FTA 0(4)-20mA 2-channel CC AO Terminal Board
  FC-TDO-1624 DO FTA 24 Vdc, 16-channel CC AI Terminal Board
  FC-TSDO-0424 Safe DO FTA 24 Vdc, 4-channel CC DO Terminal Board
  FC-TSDO-04UNI Safe digital output FTA 24/48/60/110V CC DO Terminal Board
  FC-TSDO-0824 Safe DO FTA 24 Vdc, 8-channel CC DO Terminal Board
  FC-TSDO-0824C Safe DO FTA Current limited 24 Vdc, 8-channel CC DO Terminal Board
  FC-TSDOL-0424C Safe DO FTA CL LM 24 Vdc, 4-channel CC DO Terminal Board
  FC-TPSU-2430 24 Vdc to 30 Vdc/1 A Converter CC 24-30VDC Conversion Board
  SM SM System FC-QPP-0002 Enhanced Performance Quad Processor Pack Enhanced Processor Card
  FC-USI-0001 Universal Safety Interface CC Communication Card
  FC-PSU-240516 Power Supply Unit 24/5+F159Vdc, 16A CC Power Card
  FC-BKM-0001 Battery and Key Switch Module CC Battery and Key Switch Card
  FC-SDI-1624 Safe Digital Input Module 24Vdc 16-channel CC DI Card
  FC-IO-0001 I/O Extender Module CC I/O Expansion Card
  FC-SDO-0824 Safe DO Module 24Vdc 0.55A 8-channel CC DO Card
  FC-SAI-1620M Safe Analog Input Module 4-channel CC AI Card
  FC-PDB-0824 Power Distribution Board 8ch. 24Vdc 2A CC Power Distribution Board FC-TPSU-2430 24 Vdc to 30 Vdc/1 A converter CC Power Conversion Board
  FC-TSAI-1620M Safe AI FTA 0(4)-20mA 16-channel CC AI Terminal
  FC-TSDI-1624 Safe DI FTA 24 Vdc, 16-channel CC DI Terminal
  FC-TSDO-0824 Safe DO FTA 24 Vdc, 8-channel CC DO Terminal
