The Molex SST-DN3-PCI-2 is a DeviceNet™ network interface card produced by Molex/Woodhead of the United States. It is mainly used to connect a PC to a DeviceNet network and is suitable for the field of industrial automation.
Product Features
Interfaces and Channels:
Interface Type: PCI.
Number of Channels: 2 independent interfaces, each controlled by an independent CPU, enhancing system flexibility and reliability.
Performance Parameters:
Baud Rate: Supports 125 Kbps, 250 Kbps, and 500 Kbps baud rates, meeting the requirements of various application scenarios.
Supported Protocols: DeviceNet Master, DeviceNet Slave, enabling communication with various DeviceNet devices.
High Performance: Provides high-speed data transmission, meeting the real-time and reliability requirements of industrial automation applications.
Design and Reliability:
Employs industrial-grade components to ensure long-term stable operation, suitable for harsh industrial environments.
All interfaces are default current isolated, enhancing the system’s anti-interference capability.
Has an extended temperature range (-40°C to +85°C), meeting the requirements of mobile and industrial applications.
Software Support:
Provides a virtual CAN interface (VCI), including a Windows driver package, facilitating the connection of the circuit board to applications running on a PC.
The VCI driver supports all CAN interface boards, allowing users to easily switch between different boards.
Supplies drivers for real-time Windows extensions, Linux, Silver Tail, and RTX, catering to the needs of different operating systems.
Higher-level protocols for the circuit board integrated into the network can be executed by using the SAE J1939 API or other protocol software packages, such as the CANopen Master API provided by IXXAT.
Description
Woodhead Molex SST-DN3-PCI-2
Module Number: SST-DN3-PCI-2
Brand: Woodhead Molex
Description: PCI Interface Card
Product Name
SST-DN3-PCI-2 DNSCAN P_COS_FG.stc
SST-DN3-104-2 DNSCAN P_COS_FG_104.stc
SST-DN3-PCI-1 DNSCAN
SST-DN3-104-1 DNSCAN
SST-DN3-CPCI-2 DNSCAN
SST-DN3-CPCI-1 DNSCAN
SST-DN3-VME-1 DNSCAN
SST-DN3-VME-2 DNSCAN
SST-DN3-VME-4 DNSCAN
SST Interfaces for DeviceNet
For Controlling and Monitoring DeviceNet Applications
BradCommunications SST network interface cards are ideal for applications where high-performance control and reliability are required. Backed by superior
support and service, BradCommunications network interfaces support a wide range of network protocols and bus formats.
BradCommunications SST network interface cards for DeviceNet can be found in many applications including:
Operator Interface
Human-Machine Interface
PC Control
Device Development
Network Diagnostics
BradCommunications SST network interface cards for DeviceNet undergo
DeviceNet conformance testing and support DeviceNet specifications; including
all DeviceNet standard baud rates, Poll, Strobe, Change of State (COS) and
Cyclic I/O messaging.
