Description
The PCU1000 was specially developed for use with red-y smart series controllers and meters. It enables easy display and control of these devices in situations where neither a PC nor a PLC is available or desired.
The PCU1000 communicates with up to 10 meters or controllers in any combination via an RS485 interface. Operation is menu-driven via an LCD backlit touch screen. The operating interface is available in several languages and designed so that the user will be able to cope easily straight after a short introduction. In addition, password-protected access levels can prevent operating errors.
The PCU1000 is available in two versions as panel mount or desk-top device. The electrical connections are pluggable and accessible from the back in either version. The power supply for the device and connected red-y smart is 24 Vdc. Power supply unit and bus cables are included in delivery with the desktop version.
