Product Details:
| Brand Name | EPRO |
| Model | PR6423/012-100 |
| Catalog | PR6423 |
| Origin | Germany |
| Dimension | 16*16*12cm |
| Weight | 1kg |
| HS Code | 85389000 |
| Payment | T/T |
| Sales Price | $1500 |
| Warranty | 12 months |
| Lead time | 3-5 work days |
Description:
Non-contact sensor designed for critical turbomachinery applications such as steam, gas and hydro turbines, compressors, gearboxes, pumps and fans to measure radial and axial shaft dynamic displacement; position, eccentricity and speed.
Measuring Target:
- Minimum Shaft Diameter: 25 mm (0.79’’)
- Target Material (Ferromagnetic Steel) : 45 CrMo4 (AISI/SAE 4140) Standard Other (On Request)
Additional Information:
| Compliance and Certifications | |
| CE | 2014/30/EU (EN 61326-1)
2014/34/EU 2011/65/EU |
| ATEX | EN 60079-0
EN 60079-11 |
| IEC-Ex | IEC 60079-0
IEC 60079-11 IEC 60079-26 |
| CSA | CAN/CSA-C22.2 NO. 0-M91
CAN/CSA-C22.2 NO. 157-92 CAN/CSA-C22.2 NO. 213-M1987 CAN/CSA-E60079-15-02 (R2006) CAN/CSA-C22.2 NO. 25-1966 CAN/CSA-C22.2 NO. 61010-1-04 ANSI/UL Standard 913-2004 ANSI/UL Standard 1604-1995 UL 60079-15 2002 UL 61010-1 |
