Description
The ProSoft MVI69-PDPMV1 is a high-performance PROFIBUS DPV1 Master module designed for seamless integration with Rockwell 1769-series PLCs, such as CompactLogix™ systems. It enables reliable communication between PROFIBUS DPV1 devices and Allen-Bradley controllers, offering easy data exchange in industrial environments. The module supports standard PROFIBUS DPV1 protocols, allowing for both master and slave operations, providing a versatile solution for industrial automation.
With a single-slot, standard 1769 form factor, the MVI69-PDPMV1 is easy to install and can be configured using a CIPconnect® Ethernet routing system. It simplifies communication setup and allows you to efficiently manage data transfers between various devices in your network. Whether you are working with remote sensors, actuators, or other PROFIBUS devices, this module is engineered to ensure smooth, high-speed communication, thus improving the overall performance of your control system.
Functional Highlights / Key Benefits / Main Features
- PROFIBUS DPV1 Master: Supports PROFIBUS DPV1 protocols, making it easy to integrate with a wide range of PROFIBUS devices such as remote I/O units, sensors, and actuators.
- Easy Installation: The module fits into a standard 1769 single-slot configuration, making it simple to integrate into CompactLogix™ systems.
- Comprehensive Status Indicators: Equipped with multiple LED indicators for power, module status, application status, and serial activity/error, making it easy to monitor and troubleshoot.
- Ethernet Routing with CIPconnect®: Enables Ethernet-based routing through CIPconnect®, offering flexible communication with 1769-L32E or 1769-L35E controllers.
- RS-232 Configuration Port: RJ45 to DB-9M cables are included for RS-232 configuration, providing an easy setup for system adjustments.
- Energy Efficient: The module operates efficiently, ensuring low power consumption, making it suitable for extended, continuous operations.
Technical Data / Specifications
| Parameter | Specification |
|---|---|
| Module Type | PROFIBUS DPV1 Master Module |
| Compatible PLC | Allen-Bradley 1769-series |
| Current Load | 800 mA max @ 5 VDC |
| Module Size | Standard 1769 single-slot |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95%, non-condensing |
| Indicators | Power, Module status, Application status, Serial activity/error |
| CFG Port | RJ45 (RS-232 via supplied DB-9M cable) |
| CIPconnect® | Ethernet routing with 1769-L32E or 1769-L35E |
| Included Accessories | RJ45 to DB-9M cables for each port, 6-foot RS-232 configuration cable |
Typical Applications / System Integration / Use Cases
The ProSoft MVI69-PDPMV1 is ideal for applications that require seamless communication between Allen-Bradley CompactLogix™ PLCs and PROFIBUS DPV1 devices. Typical use cases include:
- Industrial Automation Systems: Connecting PROFIBUS RTU devices such as remote I/O units, drives, and sensors for controlling and monitoring complex industrial processes.
- Machine Control: Enabling reliable communication between machines, enabling control over various devices and systems within a factory or production line.
- Energy Management: Communicating with energy meters and other measurement devices to ensure accurate data collection and energy monitoring.
- Process Control: Integrating process sensors and actuators into the control system, allowing real-time data communication for improved system optimization and control.
- Remote Device Monitoring: Facilitating data collection and remote diagnostics of PROFIBUS devices in geographically dispersed or hard-to-reach locations.
With these versatile capabilities, the MVI69-PDPMV1 module enhances your PROFIBUS network integration and simplifies communication across diverse automation systems.
Support & Maintenance / Reliability & Service
The ProSoft MVI69-PDPMV1 comes with ProSoft’s trusted support and maintenance services, ensuring maximum uptime and reliable performance:
- 24/7 Technical Support: Access expert help for troubleshooting, configuration, and system integration, minimizing system downtime.
- Firmware Updates: Ensure the module remains compatible with the latest industry standards and performance upgrades through field-upgradeable firmware.
- Warranty: Backed by a comprehensive warranty, the MVI69-PDPMV1 module is built to last and offer reliable service in industrial environments.
- User Documentation: Detailed manuals, including installation guides and configuration instructions, are available to ensure quick and easy setup.
FAQ
1. What is the purpose of the ProSoft MVI69-PDPMV1 module?
The MVI69-PDPMV1 is a PROFIBUS DPV1 Master module designed for Allen-Bradley CompactLogix™ PLCs to enable communication with PROFIBUS devices.
2. How is the module configured?
The module can be configured using the included RJ45 to DB-9M cables for RS-232 communication, along with CIPconnect® for Ethernet-based routing.
3. What are the operating conditions for the MVI69-PDPMV1?
The MVI69-PDPMV1 operates in temperatures ranging from 0°C to 60°C (32°F to 140°F) and can withstand storage temperatures from -40°C to 85°C (-40°F to 185°F).
