Description
The ProSoft MVI69E-MBS Modbus Serial Enhanced Communication Module is designed to seamlessly integrate Modbus RTU devices with Allen-Bradley CompactLogix™ systems. This versatile module supports both Master and Slave configurations across two serial ports, allowing for efficient communication with various Modbus devices. With its wide range of baud rates, flexible serial interfaces, and robust performance, the MVI69E-MBS ensures reliable connectivity in demanding industrial environments.
Built to simplify system integration, the module comes with Add-on Profiles and Instructions, streamlining commissioning and reducing development time. By facilitating quick and efficient data exchange, it improves overall productivity while maintaining system flexibility and scalability. Whether you’re looking to control remote equipment or integrate third-party devices, the MVI69E-MBS provides a comprehensive solution for your automation needs.
Functional Highlights / Key Benefits / Main Features
- Flexible Modbus Communication: Supports Master and Slave configurations, allowing for easy communication between CompactLogix and Modbus RTU devices.
- Dual Serial Ports: Features RS-232, RS-422, and RS-485 serial interfaces for versatile communication options, ensuring compatibility with a wide range of devices.
- Wide Baud Rate Range: The module supports baud rates ranging from 110 to 115.2 kbps, offering flexibility for various system speeds.
- Add-on Profiles & Instructions: Simplifies configuration and programming with built-in Add-on Profiles and Instructions, reducing setup time and effort.
- Compact Design: As a 1769 single-slot module, it integrates easily into Allen-Bradley CompactLogix™ systems without requiring additional space.
- Enhanced Reliability: Operates in a wide range of temperatures and environments, ensuring stable performance even in industrial conditions.
- Ease of Integration: Compatible with ProSoft Configuration Builder software for simple network configuration, minimizing engineering time.
Technical Data / Specifications
| Parameter | Specification |
|---|---|
| Module Type | CompactLogix™ 1769 Single-slot |
| Serial Interfaces | RS-232, RS-422, RS-485 |
| Baud Rate Range | 110 to 115.2 kbps |
| Power Supply | 5 VDC, 500 mA |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Module Dimensions | Standard 1769 module size |
| Configuration Tool | ProSoft Configuration Builder |
Typical Applications / System Integration / Use Cases
The ProSoft MVI69E-MBS is ideal for industries requiring reliable communication between Allen-Bradley controllers and Modbus RTU devices. Some typical applications include:
- Industrial Automation: Integrates remote I/O devices, sensors, and actuators into a CompactLogix™ system for process automation.
- Building Management: Interfaces with HVAC systems, lighting controls, and other equipment using the Modbus RTU protocol.
- Energy Management: Connects energy meters, remote monitoring devices, and other critical infrastructure to CompactLogix™ PLCs for data logging and control.
- Machine Control: Communicates with third-party machines, controllers, and devices to enable centralized monitoring and control in production environments.
- Remote Monitoring: Facilitates data collection and remote diagnostics by connecting Modbus RTU devices across two serial communication ports.
By enabling communication with a wide variety of Modbus devices, the MVI69E-MBS allows for customized solutions tailored to specific industrial requirements, enhancing operational efficiency and control.
Support & Maintenance / Reliability & Service
The MVI69E-MBS comes with ProSoft’s comprehensive support and maintenance services, ensuring maximum uptime and system reliability:
- 24/7 Technical Support: ProSoft provides expert assistance for troubleshooting, configuration, and system integration to ensure smooth operation.
- Firmware Updates: Field upgradeable firmware ensures that your module remains up-to-date with the latest features and enhancements.
- Comprehensive Warranty: The MVI69E-MBS is backed by a robust warranty, offering peace of mind for long-term use and support.
- User-Friendly Documentation: Detailed documentation, including configuration guides and troubleshooting tips, is available for quick reference.
FAQ
1. What types of devices can be connected to the ProSoft MVI69E-MBS?
The MVI69E-MBS allows seamless communication between Allen-Bradley CompactLogix™ systems and Modbus RTU devices such as remote I/O units, sensors, and controllers.
2. Can the MVI69E-MBS function as both a Modbus Master and Slave?
Yes, the MVI69E-MBS supports both Master and Slave configurations, providing flexibility for various system integration needs.
3. What serial interfaces are supported by the module?
The module supports RS-232, RS-422, and RS-485 serial interfaces, making it compatible with a wide range of Modbus devices.
4. How do I configure the ProSoft MVI69E-MBS?
The module can be easily configured using ProSoft Configuration Builder software, allowing users to quickly set up and manage network configurations.
5. What is the operating temperature range of the MVI69E-MBS?
The module operates within a temperature range of 0°C to 60°C (32°F to 140°F), making it suitable for most industrial environments.
